ABB 1MRK000284-AB Overcurrent Directional Time Relay Module

Application Scenarios

In a high-voltage substation utilizing ABB’s REL670 or RET670 protection relays, the system must monitor not only digital status signals but also analog process values from current transformers and voltage transformers. The 1MRK000284-AB installs permanently in Slot P12 of the protection terminal rack, providing six additional analog mA input channels that expand the relay‘s measurement capacity beyond its standard configuration . When a transformer experiences an internal fault, the protection algorithms require accurate analog measurements to calculate differential current and determine whether to initiate a trip. Without sufficient analog input channels, the protection scheme may be limited in its ability to coordinate multiple current sources or monitor auxiliary analog signals such as tap changer position or oil temperature. The 1MRK000284-AB addresses this gap by enabling expanded analog measurement without requiring a separate standalone monitoring device, ensuring that the protection terminal has complete visibility of all relevant process parameters .

Parameter
