Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 80022-153-03-01 (variant -A) |
| Manufacturer | ABB |
| Product Type | Operator Interface / Industrial HMI Touchscreen Terminal |
| Display Size | 15 inches, TFT LCD |
| Resolution | 1280 × 800 pixels |
| Touch Technology | Capacitive touchscreen with integrated function keys |
| Processor | Intel Atom class processor, 1 GHz |
| Memory | 512 MB RAM with onboard flash storage |
| Operating System | Embedded real-time operating system (RTOS) |
| Input Power | 24 Vdc nominal (12–24 Vdc operating range) |
| Power Consumption | Up to 30 W |
| Communication Interfaces | Ethernet, RS-485, RS-232, USB |
| Supported Protocols | Modbus TCP/IP, Modbus RTU, ASCII |
| Front Panel Protection | IP65 (dust-tight and protected against water jets) |
| Operating Temperature | −20 °C to +55 °C |
| Storage Temperature | −30 °C to +70 °C |
| Humidity Range | 5 % to 95 % RH, non-condensing |
| Mounting | Panel mount, cabinet door or console installation |
| Dimensions (W × H × D) | Approximately 340 mm × 260 mm × 60 mm |
| Weight | Approximately 2.5 kg |
| Certifications | CE, UL, CSA |
Main Features and Advantages
Display size matched to real operator workload: A 15-inch screen at 1280 × 800 gives the ABB 80022-153-03-01 enough canvas to show a process overview, live trending and an active alarm list at the same time. That matters more than raw resolution suggests: during a disturbance, an operator who can see the value, its trend and its alarm state on one screen makes a decision in seconds, while one forced to navigate between pages loses the time window in which intervention is cheapest.
Capacitive touch with tactile function keys: The ABB 80022-153-03-01 supports capacitive touch input for navigating customised graphical screens, and supplements it with integrated physical keys for the actions that must never depend on hitting a small target — acknowledge, page change, or start/stop confirmations. Capacitive sensing also eliminates the drifting and recalibration that resistive panels suffer after years of use, so touch accuracy at year ten still matches commissioning day.
Industrial connectivity without gateways: With Ethernet, RS-485 and RS-232 on board and Modbus TCP, Modbus RTU and ASCII in firmware, the ABB 80022-153-03-01 connects directly to the majority of installed PLCs, drives, protection relays and package controllers. In retrofit work this removes the cost, panel space and failure point of a protocol converter, and it lets one terminal serve as the local face for equipment from several different vendors.
Sealed front panel for the mounting position it actually gets: The IP65 front rating means the ABB 80022-153-03-01 can be installed on a washdown-area cabinet, a dusty material handling console, or a humid pump station panel without an additional protective cover that inevitably fogs, yellows and gets removed. Combined with a −20 °C to +55 °C operating range, it tolerates cabinets without climate control.
Customisable graphics and diagnostics: Screens are built to suit the process rather than forcing the process into a fixed template, so the ABB 80022-153-03-01 can present machine-specific layouts, multilingual text and built-in diagnostic pages that let maintenance staff read communication status and fault information at the panel instead of connecting a laptop in a permit-controlled area.
