Application Scenarios
In a provincial power utility dispatch data network, hundreds of Alcatel-Lucent OmniSwitch 6850E and 6860 switches form the backbone connecting substations to the master station. When the original 1AB196370003 modules reached end-of-life and the OEM quoted a 12-week lead time at a prohibitive price, the network engineering team turned to The Gigatech-compatible 1AB196370003. Once inserted into the OmniSwitch 6860 SFP slot, the module was instantly recognized by the switch operating system; the CLI command show interface transceiver returned complete DDM data—temperature, supply voltage, TX/RX optical power—identical in format to the original modules. Over a 6-month continuous operation period, the 1AB196370003 delivered zero bit errors and zero compatibility alarms across the backbone, while reducing per-port optical module cost by more than 50%.
Beyond power utilities, the 1AB196370003 is equally valuable in rail transit CBTC backbone networks, factory DCS communication rings, and university/hospital legacy core networks—anywhere Alcatel-Lucent OmniSwitch equipment remains in service and budget constraints preclude a full network refresh.
Parameters
| Main Parameters | Value / Description |
|---|---|
| Product Model | 1AB196370003 |
| Manufacturer | The Gigatech (compatible with Alcatel-Lucent / Nokia) |
| Product Category | Gigabit SFP Single-Mode Optical Transceiver Module |
| Compatible Brand / Series | Alcatel-Lucent / Nokia OmniSwitch 6850 / 6860 / 6900 / 7800 |
| Transmission Rate | 1.25 Gbps (1000BASE-LX) |
| Wavelength | 1310 nm |
| Transmission Distance | 10 km over G.652 single-mode fiber |
| Interface Type | LC Duplex |
| TX Optical Power | -9.9 to -3 dBm |
| RX Sensitivity | ≤ -23 dBm |
| DDM / DOM Support | Yes (real-time temperature, voltage, TX/RX power monitoring) |
| Supply Voltage | 3.3 V |
| Power Consumption | < 0.8 W |
| Protocol Compliance | IEEE 802.3z, 1000BASE-LX |
| Operating Temperature | 0 °C to +70 °C (commercial grade) |
