Product Overview
The Honeywell 38001704-100 is a high-performance analog input module designed for precise signal acquisition in industrial automation and process control systems. As a critical interface component within Honeywell’s control architecture, the Honeywell 38001704-100 converts field analog signals from sensors and transmitters into digital data suitable for processing by PLC, DCS, and other control platforms. This module addresses the fundamental need for accurate, reliable measurement of process variables such as temperature, pressure, flow, and level across manufacturing, energy, and chemical industries.
The Honeywell 38001704-100 supports a wide range of input signal types, accommodating both current and voltage sources to maximize compatibility with diverse field instrumentation. Its multi-channel design enables efficient handling of multiple sensor inputs within a single compact unit, reducing panel space requirements and simplifying wiring architecture. The module incorporates advanced signal conditioning technology that maintains measurement integrity even in electrically noisy industrial environments, ensuring that control decisions are based on trustworthy data.
Positioned as a versatile solution for both new installations and system upgrades, the Honeywell 38001704-100 delivers the precision and durability that industrial operators demand. Its robust construction and wide operating temperature range make it suitable for deployment in demanding conditions, while standardized communication interfaces facilitate seamless integration into existing control networks.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | Honeywell 38001704-100 |
| Manufacturer | Honeywell |
| Product Type | Analog Input Module |
| Input Channels | 8 (standard configuration) |
| Input Signal Range | 4-20 mA / 0-10 V DC / -10 V to +10 V |
| Resolution | 12-bit to 16-bit (configuration dependent) |
| Accuracy | ±0.1% to ±0.2% Full Scale |
| Communication Interface | Modbus RTU, RS-485 |
| Power Consumption | 1 W to 2 W (typical) |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -55°C to +125°C |
| Protection Rating | IP65/IP67 (certain configurations) |
| Mounting Type | DIN-Rail Compatible |
| Certifications | CE, UL, RoHS |
Main Features and Advantages
The Honeywell 38001704-100 distinguishes itself through a combination of measurement precision, operational flexibility, and environmental resilience that addresses the practical demands of industrial signal acquisition. Its multi-channel architecture enables simultaneous processing of multiple analog inputs, making the Honeywell 38001704-100 an efficient solution for applications where sensor density is high and panel space is limited.
Precision signal conversion: The Honeywell 38001704-100 achieves measurement accuracy within ±0.1% to ±0.2% of full scale, ensuring that control systems receive reliable data for critical process decisions. This level of precision supports applications ranging from flow measurement in custody transfer to temperature control in exothermic reactions where accuracy directly impacts product quality and safety.
Versatile input compatibility: The Honeywell 38001704-100 accepts both current and voltage input signals, accommodating 4-20 mA transmitters, 0-10 V sensors, and bipolar signal sources within a single module. This flexibility simplifies inventory management and reduces the number of distinct module types required across a facility, while also easing the transition from legacy instrumentation to modern control systems.
Robust environmental performance: Engineered for harsh industrial conditions, the Honeywell 38001704-100 operates reliably across a temperature range of -40°C to +85°C. Certain configurations provide IP65/IP67 protection, enabling deployment in environments where dust, moisture, and washdown are routine concerns. The module also incorporates overvoltage and ESD protection, safeguarding against electrical transients that can damage sensitive input circuitry.
Seamless system integration: The Honeywell 38001704-100 supports Modbus RTU communication over RS-485, a widely adopted protocol that ensures compatibility with most PLC, DCS, and SCADA platforms. DIN-rail mounting and user-friendly terminal connections facilitate rapid installation and maintenance, minimizing downtime during commissioning or module replacement.
