Honeywell 51195066-200 TDC Micro Power Supply – 10-Slot Chassis, 8.75 / 5.25 A Dual Rail

Description

The Honeywell 51195066-200​ is a TDC Micro system power supply manufactured by Honeywell, classified as a chassis power supply / DCS power module within the Honeywell TDC 3000 / TDC Micro distributed control system family. It is the dedicated power source for Honeywell’s 10-slot chassis, delivering regulated multi-rail DC power to the processors, I/O modules, and communication cards mounted in that chassis.

The 51195066-200​ is the newer-generation replacement for the original 51400712-200, retaining the original 8-pin chassis connector for direct drop-in installation. Its defining electrical characteristic — reflected in the model’s common designation — is a dual-output power stage rated at 8.75 A on the primary rail and 5.25 A on the secondary rail, supplying the +5 V and +24 V / auxiliary power required by TDC Micro electronics. For legacy DCS plants, it is the difference between a risky, obsolete-power-supply gamble and a tested, reliable return to stable operation.

Application Scenarios

In a petroleum-products terminal running a Honeywell TDC 3000 system, the 10-slot controller chassis had been on original power supplies for nearly two decades. After one unit developed a low +5 V rail during a summer heatwave — causing intermittent I/O card resets that were painful to diagnose — the maintenance team sourced the Honeywell 51195066-200​ as a direct replacement. Because the new supply retained the original 8-pin connector and chassis mounting form, installation took minutes: isolate AC, unplug the old unit, seat the 51195066-200, restore power, and verify the +5 V and +24 V rails. The refurbished-and-tested unit, built with new electrolytic capacitors, held steady output through the next heat cycle, and the intermittent resets disappeared.

This case illustrates the practical role of the 51195066-200: it is the life-support rail for an entire DCS chassis. In oil refineries, chemical plants, power stations, and continuous-process facilities running aging TDC 3000 / TDC Micro systems, the Honeywell 51195066-200​ addresses the recurring pain points of failing electrolytic capacitors, drift on the critical +5 V logic rail, incompatible replacement form factors, and the high cost and long lead time of OEM-new spares. By restoring clean, regulated power with a direct-fit unit, it protects the I/O and processor modules downstream — and with them, the availability of the entire control system.

Parameter
