Product Overview
The Honeywell 8C-TDOD51 (51306979-175) is a redundant digital output module for the Honeywell Experion Series C control platform. It installs in a Series C input/output terminal assembly, or IOTA, and works with redundant controller and I/O configurations to maintain deterministic on/off control during a module, power, or communication failure. Rather than merely switching a discrete load, the Honeywell 8C-TDOD51 provides fault-tolerant, bidirectional DC output capability that is integrated with Experion process control and asset-management functions.
The module provides 16 isolated digital output channels. Each channel can operate as a current-sinking or current-sourcing output at 24 VDC, with a rated load current of 0.5 A. Output states are determined by the control application and transmitted through the redundant Series C communication and backplane architecture. Diagnostic information, module health, and output status are visible to the control system, which supports predictive maintenance and faster fault isolation.
The Honeywell 8C-TDOD51 51306979-175 is especially valuable in continuous-process industries where an unexpected loss of a solenoid, valve, pump starter, alarm, or interlock output can create safety, environmental, or production consequences. Used with redundant Series C I/O and controllers, it helps maintain the control action associated with the configured output state. Because the module is now obsolete, verified spares, correct IOTA terminations, and compatible firmware are critical to successful replacement.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | 8C- |
| Part/Order Reference | 51306979-175 |
| Manufacturer | Honeywell International Inc. |
| Product Type | Redundant digital output module |
| Control Platform | Honeywell Experion Series C |
| Compatible Controllers | Redundant C300 controller |
| Output Channels | 16, electrically isolated |
| Output Voltage | 24 VDC nominal |
| Output Configuration | Sink or source, jumper/configurable |
| Rated Load Current | 0.5 A per channel |
| Module Power | 24 VDC from IOTA |
| Module Power Consumption | 12 W |
| On-State Voltage Drop | Less than 1.0 V |
| Off-State Leakage Current | Less than 1.0 mA |
| Turn-On/Turn-Off Time | Less than 1.0 ms |
| Communication | Redundant Series C I/O bus |
| Redundancy | Redundant output pair / redundant I/O architecture |
| Diagnostics | Open circuit, short circuit, overcurrent, overtemperature, internal fault, module health |
| Isolation | Channel-to-channel and field-to-logic isolation |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5% to 95%, non-condensing |
| Enclosure Rating | IP20, cabinet-mounted |
| Compliance | CE, RoHS; cULus Class I Division 2, ATEX, IECEx where marked |
