Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 00-205-143 |
| Manufacturer | KUKA AG |
| Product Type | KBR Series Power Supply Module |
| Compatible Systems | KUKA KRC2 controller family and related KR-series robot cabinets |
| Input Voltage | 100–240 VAC, 50/60 Hz (variant-dependent; commonly 230 VAC) |
| Output Voltage | 24 VDC regulated (variant-dependent) |
| Output Current | Up to 10 A (variant-dependent) |
| Rated Output Power | Approximately 240 W (variant-dependent) |
| Conversion Technology | Switched-mode power supply (SMPS) |
| Efficiency | Greater than 85% typical |
| Protection Features | Overvoltage, overcurrent and short-circuit protection |
| Cooling Method | Natural convection / enclosure heat dissipation |
| Mounting Method | Controller chassis or cabinet mounting; compatible with standard installation positions |
| Operating Temperature | 0 °C to +55 °C typical |
| Storage Temperature | -25 °C to +85 °C |
| Protection Rating | IP20 |
| Weight | Approximately 0.4 kg |
| Certifications | CE; selected variants UL/CSA listed |
Main Features and Advantages
The KUKA 00-205-143 delivers stable, filtered DC power tailored to the requirements of KUKA controller electronics. Its switched-mode design provides efficient voltage conversion with relatively low heat generation, helping maintain a clean electrical environment inside the control cabinet.
Stable power for controller electronics:
The module supplies the internal PC motherboard, processor, memory, storage devices and control circuitry. By maintaining a regulated DC output, the KUKA 00-205-143 helps ensure consistent controller operation during normal running, startup and recovery from power interruptions.
Integrated electrical protection:
Built-in overvoltage, overcurrent and short-circuit protection monitors the output and responds to abnormal load conditions. This helps prevent a fault in the power supply or connected circuitry from propagating to more expensive controller components.
Cabinet-qualified construction:
Designed for installation in KUKA controller enclosures, the KUKA 00-205-143 uses a form factor and connection arrangement suited to its intended cabinet location. This simplifies replacement and reduces installation time during maintenance or system restoration.
Low-noise power conversion:
The module’s filtering and regulation characteristics help reduce voltage ripple and susceptibility to mains disturbances. For sensitive control electronics, this contributes to reliable operation in electrically demanding industrial environments.
Practical spare-part value:
Because the power supply supports the controller’s core computing and control hardware, a failed unit can disable an entire robot. Keeping a verified KUKA 00-205-143 available as a spare allows maintenance teams to restore operation quickly and minimize unplanned downtime.
