Product Overview
The Parker 690-432300C0-B00P00-A400 is a 15kW (20HP) three-phase AC variable frequency drive from the renowned Parker SSD 690+ Integrator Series. This high-performance drive represents a benchmark in industrial motor control, combining advanced 32-bit microprocessor technology with exceptional flexibility to handle everything from basic single-motor speed control to sophisticated integrated multi-drive systems . The Parker 690-432300C0-B00P00-A400 operates with a 380-460V three-phase input supply and delivers 31A output current under constant torque conditions, making it ideal for demanding industrial applications requiring precise speed and torque regulation .
At the heart of the Parker 690-432300C0-B00P00-A400 lies a sophisticated MRAS (Model Reference Adaptive System) motor control strategy that enables sensorless vector control without requiring speed feedback devices. For applications demanding the highest performance levels, users can simply add an encoder feedback technology box to unlock full closed-loop flux vector control, delivering 100% continuous full load standstill torque and dynamic speed loop bandwidth up to 45Hz . The drive’s Frame C construction measures 201mm wide × 348mm high × 208mm deep, providing a compact yet powerful solution for panel-mounted installations in industrial control cabinets .
The Parker 690-432300C0-B00P00-A400 has established a reputation for reliability and ease of use since its release in 1999, with production spanning over two decades . While the 690+ series has reached obsolescence due to critical component discontinuation, the Parker 690-432300C0-B00P00-A400 remains actively sought after by facilities maintaining legacy automation infrastructure, with refurbished units available and Parker offering AC20 series crossover replacements for modernization projects .
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | Parker 690-432300C0-B00P00-A400 |
| Manufacturer | Parker Hannifin / SSD Drives |
| Product Type | AC Variable Frequency Drive |
| Series | AC690+ Integrator |
| Frame Size | C |
| Input Voltage | 380-460V AC, 3-Phase, ±10% |
| Input Frequency | 50/60Hz |
| Output Power (Constant Torque) | 15kW (20HP) |
| Output Power (Variable Torque) | 18.5kW (25HP) |
| Output Current (Constant Torque) | 31A |
| Output Current (Variable Torque) | 38A |
| Output Frequency | 0-480Hz |
| Overload Capacity | 150% for 60s, 180% for 1s |
| Control Modes | V/Hz, Sensorless Vector, Closed-Loop Vector |
| Dimensions (W×H×D) | 201 × 348 × 208 mm |
| Weight | Approximately 9.3 kg |
| Protection Rating | IP20 (standard) |
