Product Overview
The SOLID STATE 80-219310-90 is an industrial-grade printed circuit board (PCB) manufactured by Solid State Controls, a company whose products serve as OEM core boards for multiple major industrial equipment manufacturers. Unlike general-purpose PCBs, the SOLID STATE 80-219310-90 is a “one-part-number, multiple-application” component—the same model number appears across different parent equipment platforms from GE, Eaton/Cutler-Hammer, and Westinghouse, with each application having distinct electrical parameters, interface definitions, and firmware programs . This characteristic makes the SOLID STATE 80-219310-90 a critical but application-specific spare part that requires careful verification before procurement.
Documented applications for the SOLID STATE 80-219310-90 include three primary parent platforms. In the first application, it serves as the core circuit board for the GE Fanuc Series 90-30 PLC, specifically within the IC693MDL940 digital output module—a 16-channel solid-state DC output module rated 24-48V DC at 0.5A per point . The second application positions the SOLID STATE 80-219310-90 as the core control board for Eaton/Cutler-Hammer Westinghouse A/DA/DAF series low-voltage air circuit breakers, functioning as the solid-state trip unit (SST) that integrates microprocessor control, current sensor interfaces, and output drive circuits for overload, short-circuit, and ground fault protection . A third documented use involves Solid State Controls industrial UPS systems and static transfer switches (STS), where the board manages voltage monitoring, battery charging, and power switching logic .
The SOLID STATE 80-219310-90 is constructed on FR-4 epoxy glass substrate with through-hole mounting and industrial-grade wide-temperature design. Its value proposition is fundamentally tied to the parent equipment it serves—when a critical production asset halts due to a failed core board, the operational loss can reach tens of thousands of dollars per day, making the SOLID STATE 80-219310-90 a high-consequence spare that demands correct identification and sourcing .
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | SOLID STATE 80-219310-90 |
| Manufacturer | Solid State Controls |
| Product Type | Industrial Control PCB Circuit Board |
| Material | FR-4 Epoxy Glass / High-Grade Copper Clad Laminate |
| Mounting Style | Through-Hole / Panel Mount |
| Operating Temperature Range | -40°C to +85°C (varies by application) |
| Primary Application 1 | GE Fanuc Series 90-30 PLC, IC693MDL940 Digital Output Module (16-channel, 24-48V DC, 0.5A/point) |
| Primary Application 2 | Eaton/Cutler-Hammer Westinghouse A/DA/DAF Low-Voltage Air Circuit Breaker SST Core Board |
| Primary Application 3 | Solid State Controls Industrial UPS / Static Transfer Switch (STS) Control Board |
| Certifications | UL, CE, RoHS (application-dependent) |
| Power Consumption | Up to 10W (typical) |
| Interface Type | Application-specific; varies by parent equipment |
