Product Overview
The VIPA 315-2AG10 is a high-performance processor module from the VIPA System 300V series, designed as a central processing unit for industrial automation applications requiring reliable control and seamless integration. As a member of the CPU 315SB family, the 315-2AG10 serves as the computational core of modular PLC systems, executing control programs, managing I/O data, and coordinating communication between distributed modules and higher-level systems. The VIPA 315-2AG10 is engineered to be configured as a Siemens CPU 315-2DP within the SIMATIC Manager hardware configurator, allowing engineers familiar with Siemens programming environments to deploy the VIPA module without extensive retraining .
The 315-2AG10 incorporates a 32-bit microprocessor architecture that delivers deterministic execution of complex control algorithms, making it suitable for demanding industrial applications ranging from manufacturing automation to process control. The module supports multiple programming languages including Ladder Diagram, Structured Text, and Statechart Functions, providing flexibility for development teams with diverse skill sets . With integrated MPI and PROFIBUS DP communication interfaces, the VIPA 315-2AG10 facilitates seamless integration into existing industrial networks and enables efficient data exchange with remote I/O modules, drives, and supervisory systems .
The 315-2AG10 is designed for DIN-rail mounting within VIPA System 300V racks, offering a compact footprint that conserves valuable control cabinet space. The processor module’s robust construction and wide operating temperature range ensure reliable performance in diverse industrial environments, from climate-controlled electrical rooms to more challenging production floor installations. As a proven component in legacy and current automation systems, the VIPA 315-2AG10 represents a dependable solution for both new projects and spare-part replacements in existing installations.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 315-2AG10 (CPU 315SB) |
| Manufacturer | VIPA |
| Product Type | Central Processing Unit / Processor Module |
| Product Series | System 300V |
| Processor Architecture | 32-bit Microprocessor |
| Operating Voltage | 24 V DC |
| Power Consumption | ≤ 6 W |
| Work Memory | 1 MB (typical), Expandable up to 2 MB |
| Communication Interfaces | MPI, PROFIBUS DP |
| Programming Languages | Ladder Diagram (LAD), Structured Text (ST), SFC |
| Digital Input Channels | 16 (integrated) |
| Digital Output Channels | 16 (integrated) |
| Operating Temperature | -20°C to +60°C |
| Dimensions (W × H × D) | 40 × 125 × 130 mm (approximate) |
| Weight | Approx. 0.5 kg |
| Siemens Compatibility | Configurable as CPU 315-2DP (315-2AG10-0AB00 V2.6) |
