WAGO 750-625/000-001 24 VDC 240 W Power Supply for Industrial Automation

Description

The WAGO 750-625/000-001​ is a power supply module manufactured by WAGO Kontakttechnik GmbH for the 750 series of modular I/O systems. It is the module that converts incoming AC mains into the 24 VDC rail used by the I/O rack, delivering both the field-side operating voltage and the internal system power required for the fieldbus coupler and connected I/O modules.

Housed in the characteristic IP20 enclosure of the 750 series and designed for DIN-rail mounting, the WAGO 750-625/000-001​ provides up to 10 A at 24 VDC, equivalent to 240 W of output power. It includes integrated diagnostic capability, allowing the control system to detect and report supply conditions rather than discovering a dead rack only when the process stops.

Application Scenarios

Consider a water treatment plant where a 750 series I/O rack sits in a panel beside a river pump station, handling level transmitters, pump contactors, and valve position feedback for a dozen remote sites. The panels are not air-conditioned, the incoming supply fluctuates with the utility, and the maintenance team is based an hour away. When a power supply drifts or fails, the entire rack loses its field power at once—every input goes stale and every output drops, which looks exactly like a field device failure until someone opens the panel.

The WAGO 750-625/000-001​ changes that failure from a mystery into a known event. Because the module carries its own diagnostics, the control system sees the supply condition directly and can raise an alarm before the rack collapses entirely. A technician arrives with the correct spare already in the truck, and the replacement takes minutes rather than the hours that would have been spent tracing a phantom field wiring fault. In a distributed plant where panels are scattered across a large site, that difference in diagnosis time is the real value of the module.
