Application Scenarios
In a precision CNC machining center, the tool turret must index to exact angular positions with repeatable accuracy measured in arc-seconds. When the turret rotates to select a new tool, even a slight positioning error can cause the tool holder to misalign with the spindle, leading to surface finish defects or catastrophic tool breakage. The A06B-0104-B111#7000 addresses this challenge through its high-resolution encoder feedback and rapid dynamic response. Mounted directly on the turret indexing mechanism, the motor receives position commands from the CNC controller and executes precise movements with minimal overshoot. For machine tool builders and maintenance engineers, the A06B-0104-B111#7000 delivers the reliability and repeatability required to maintain micron-level tolerances across thousands of tool changes per shift.
Parameter
| Main Parameters | Value/Description |
|---|---|
| Product Model | A06B-0104-B111#7000 |
| Manufacturer | GE Fanuc / FANUC |
| Product Category | AC Servo Motor |
| Motor Type | AC Servo Motor, Alpha Series |
| Rated Power | 0.11 kW (110 W) |
| Rated Speed | 1000 RPM |
| Maximal Torque | 0.15 Nm |
| Operating Voltage | 230 V AC |
| Control Interface | Digital Input |
| Feedback Device | Sin/Cos Encoder (High-Resolution) |
| Protection Class | IP54 (Dust and Splash Resistant) |
| Mounting Style | Flange Mount |
| Weight | 0.6 kg |
Innovation Point 1: Sin/Cos Encoder for Sub-Micron Position Feedback. The A06B-0104-B111#7000 incorporates a sinusoidal encoder that generates analog sine and cosine signals as the motor shaft rotates. Unlike standard incremental encoders that output discrete pulses, the Sin/Cos encoder provides continuous position information that the drive interpolates to resolutions far exceeding the encoder’s fundamental line count. This capability enables the A06B-0104-B111#7000 to achieve the precise positioning required for high-accuracy machining and robotic assembly tasks, where even a single encoder count of error can propagate into unacceptable workpiece deviation.
Innovation Point 2: Compact Design for Space-Constrained Integration. With a weight of only 0.6 kg and a flange-mount configuration, the A06B-0104-B111#7000 is designed for direct integration into compact mechanical assemblies where space is at a premium. This is particularly valuable in multi-axis machine tools and compact robotic joints, where motor bulk can limit axis travel or interfere with tooling. The lightweight construction also reduces the inertial load on the axis, allowing faster acceleration and deceleration for shorter cycle times.
Innovation Point 3: IP54 Environmental Protection for Industrial Environments. The #7000 carries an IP54 protection rating, safeguarding the motor’s internal components against dust ingress and water splashes from any direction. In machining environments where coolant mist and metal chips are ubiquitous, this protection level ensures that the motor maintains reliable operation without requiring additional enclosures or shielding. The #7000 is designed for air cooling, allowing continuous operation in the thermal conditions typical of machine tool cabinets and industrial work cells.
