Application Scenarios
A high-speed packaging line was struggling with relay output modules that couldn’t keep pace with the machine’s rapid cycling demands. Frequent relay wear and contact welding caused production stoppages nearly every week. The maintenance team replaced the relay modules with 3D04806 transistor output modules, leveraging the module’s 500 Hz switching capability and 4 µs turn-on delay to directly drive pneumatic valves and solenoids at high cycle rates. The result was a 30% increase in production throughput and near-elimination of output-related failures, as the solid-state design withstood continuous high-frequency operation that would have destroyed mechanical relays within months.
Parameters
| Main Parameters | Value/Description |
|---|---|
| Product Model | 3D04806 / 3DO480.6 (official) |
| Manufacturer | B&R (Bernecker + Rainer, now ABB Group) |
| Product Series | 2005 Series (legacy rack-based I/O) |
| Product Category | Digital Output Module (16-channel transistor) |
| Output Channels | 16, split into 2 isolated groups (8 channels each) |
| Output Type | Transistor (PNP sourcing), non-relay |
| Load Voltage | 24 V DC (absolute max 0–48 V DC) |
| Current per Channel | 2.0 A (resistive load) |
| Group Current Limit | 12.0 A (75% simultaneity) |
| Switching Frequency | Max 500 Hz (resistive load) |
| Turn-on Delay | Typical 4 µs / max 120 µs |
| Turn-off Delay | Typical 100 µs / max 120 µs |
| Short-Circuit Protection | Built-in with auto-recovery (~1 s) |
| Isolation | Group-to-group; channel-to-PLC bus; no channel-to-channel within group |
| Status Indication | Per-channel LEDs + group overload LEDs |
| Terminal Blocks | TB170.9 (screw) or TB170.91 (spring) – sold separately |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Installation | Plug-in to 2005 series rack backplane |
| Protection Rating | IP20 (cabinet-mounted) |
