Product Overview
The Allen-Bradley 20BD096A0AYNANB0 is a high-performance adjustable frequency AC drive from the renowned PowerFlex 700 series, engineered for precise motor control in industrial automation applications. This Allen-Bradley 20BD096A0AYNANB0 operates at 480 VAC with a three-phase input, delivering up to 96 amps of output current with a nominal motor power rating of 75 HP for normal duty applications and 60 HP for heavy duty requirements. As a member of the widely deployed PowerFlex 700 platform, the Allen-Bradley 20BD096A0AYNANB0 provides reliable and efficient speed control for three-phase induction motors in manufacturing, process, and utility environments.
The Allen-Bradley 20BD096A0AYNANB0 features standard control methodology with a 120V I/O interface, facilitating straightforward integration with various motor types and existing control systems. The drive incorporates an installed brake IGBT, enabling controlled deceleration of motor loads and dynamic braking capability in applications requiring rapid stopping or holding torque. Its IP20 enclosure rating, conforming to NEMA/UL Type 1 standards, makes the Allen-Bradley 20BD096A0AYNANB0 suitable for indoor installations within control cabinets where protection against dust and accidental contact is required.
Within the broader industrial automation ecosystem, the Allen-Bradley 20BD096A0AYNANB0 functions as a central component for motor speed and torque regulation, converting fixed-frequency AC power into variable-frequency, variable-voltage output to match motor load requirements. By adjusting motor speed to align with process demand, the Allen-Bradley 20BD096A0AYNANB0 delivers substantial energy savings in fan, pump, and centrifugal load applications while providing precise control for conveyors, mixers, and other mechanical systems. Its robust construction and proven design make the Allen-Bradley 20BD096A0AYNANB0 a trusted solution for demanding industrial environments where reliability and performance are paramount.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 20BD096A0AYNANB0 |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Product Type | Adjustable Frequency AC Drive |
| Product Line | PowerFlex 700 |
| Series | Series A |
| Input Voltage | 480 VAC, 3-Phase |
| Output Current | 96 Amps |
| Nominal Motor Power (Normal Duty) | 75 HP |
| Nominal Motor Power (Heavy Duty) | 60 HP |
| Control Method | Standard Control with 120V I/O |
| Brake IGBT | Installed |
| Internal Brake Resistor | Not Installed |
| Human Interface Module | No HIM (Blank Plate) |
| Enclosure Rating | IP20, NEMA/UL Type 1 |
| Carrier Frequency | 4 kHz |
| Ambient Operating Range | 0°C to 40°C |
| Storage Temperature | -40°C to +70°C |
| Dimensions (W×H×D) | 308.9 mm × 644.5 mm × 275.4 mm |
| Weight | 82.0 lb (37.19 kg) |
| Communication Module | Not Included |
| Feedback | Not Included |
