Description
The 2711P-T10C4A8 is a 10.4-inch, touch-only operator terminal from the Allen-Bradley PanelView Plus 6 1000 family, manufactured by Rockwell Automation. It gives a machine-level interface a 640 × 480 colour TFT, a gloved-finger resistive touchscreen and two built-in communication paths — Ethernet for EtherNet/IP and a 9-pin serial port for DF1, DH-485 and legacy instrument links — all running on Windows CE 6.0 under FactoryTalk View ME.
What the 2711P-T10C4A8 really represents is continuity. It is the terminal you reach for when the panel cutout, the AC supply and the .MER application are already fixed assets, and the only acceptable outcome is a swap that takes less time than the shift handover.
Application Scenarios
A packaging machine has run the same PanelView for eleven years. The operator knows exactly where the “pouch length” soft-key sits, the maintenance laptop still carries the original FactoryTalk View ME project, and the RS-232 link to an old barcode scanner was never worth upgrading. Then the screen starts flashing — the CCFL is tired, the inverter is noisy, and on cold Monday mornings the backlight takes three minutes to strike.
That is the moment the 2711P-T10C4A8 earns its place on the spare shelf. Drop in an identical unit, keep the 224 × 269 mm cutout, keep the 100–240 VAC supply as it is, reload the application from the SD card or over Ethernet, and the operator is tapping the same pouch-length key within the hour. No screen remap, no new panel door, no requalification of the interface. The machine does not care that the model is out of catalogue.
Parameter
| Main Parameters | Value / Description |
|---|---|
| Product Model | 2711P-T10C4A8 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Category | PanelView Plus 6 1000 operator terminal (touch-only, standard communication) |
| Display | 10.4 in colour active-matrix TFT, 640 × 480 VGA, 18-bit colour graphics |
| Active Viewing Area | 211 × 158 mm (8.3 × 6.2 in) — the usable part of the 10.4 in diagonal |
| Operator Input | 8-wire analog resistive touch, 1 million press cycles, 10–110 g actuation force |
| Operating System | Windows CE 6.0, standard build without the Extended Features / desktop file viewers |
| Runtime Software | FactoryTalk View Machine Edition 6.0 or later; applications load as .MER runtime |
| Memory | 512 MB RAM + 512 MB non-volatile flash; approx. 79 MB free user/project memory |
| Communications | 1 × RJ45 10/100 Ethernet (EtherNet/IP, TCP/IP), 1 × RS-232/422/485 9-pin, 2 × USB host |
| Expansion | Backplane-ready for optional DH+, DH-485 or ControlNet module; SD card slot (1784-SDx, hot-swappable) |
| Power Input | 100–240 VAC, 50/60 Hz (catalogue “A” = AC; 85–264 VAC tolerance on the family) |
| Power Draw | 160 VA max, 65 VA typical — roughly the appetite of a small desk lamp, not a cabinet heater |
| Backlight | CCFL, 50,000 hour minimum design life at 25 °C, field-replaceable as an assembly |
| Real-Time Clock | Battery-backed, ±2 min/month; CR2032 (2711P-RY2032), field-replaceable, 4 yr minimum life |
| Front Protection | NEMA Type 12, 13 and 4X indoor; IEC IP65 front, IP54 rear |
| Environment | 0 to +55 °C operating, −25 to +70 °C storage, 5–95% RH non-condensing, up to 2,000 m altitude |
| Form Factor | Panel-mount, approx. 329 × 248 × 55 mm, 2.5–2.6 kg; cutout 224 × 269 mm (8.82 × 10.59 in) |
| Languages / Security | 67 online languages, two password levels, alarm acknowledgement and message buffering |
| Certifications | UL Listed, cUL, CE, CSA, RoHS |
| Lifecycle | Discontinued (end-of-life); replacement via certified surplus, repair or migration to PanelView Plus 7 |
Technical Principles and Innovative Values
Innovation Point 1 — The catalogue number is a wiring diagram in disguise. Break 2711P-T10C4A8 down and every character tells you what you can skip checking: T for touch-only, 10 for the 1000 size class, C for colour TFT, 4 for the Ethernet-plus-RS-232 base communication set, A for AC input, 8 for the Windows CE 6.0 standard logic. That is why a technician can confirm a compatible spare from a photo of the label in ten seconds instead of tracing three cables and a cutout template.
Innovation Point 2 — Resistive touch chosen for the real world, not the showroom. The 8-wire analog film responds to a bare finger, a nitrile glove or a plastic stylus with at least a 1.3 mm tip radius. Capacitive screens hate that combination. The rated actuation force (10–110 g) is light enough for an eight-hour shift and firm enough that a grease smear does not register as a button press. When it does drift, a recalibration in configuration mode fixes it — no glass replacement required.
Innovation Point 3 — Two transport paths for the application, deliberately. Ethernet is the fast way: download the .MER from FactoryTalk View ME Studio over the RJ45. The 9-pin serial port is the stubborn way, and it is the one that saves you when the network is isolated, the switch is dead or the terminal is air-gapped by policy. Add the SD slot and you have a third: carry the runtime on a card in your pocket. For a terminal this old, three routes to the same file are not a luxury; they are the reason it is still running.
Innovation Point 4 — The field-replaceable everything philosophy. Bezel, touch overlay, backlight and RTC battery are all serviceable without a re-certification event. The CCFL is rated to 50,000 hours at 25 °C, which sounds like forever until you realise a three-shift plant racks up roughly 6,500 hours a year. The 2711P-T10C4A8 is designed so that “the backlight died” is a Friday-afternoon job, not a shutdown project.
Innovation Point 5 — Same cutout as the PanelView Standard and Enhanced before it. Rockwell carried the 224 × 269 mm opening across three generations. Mechanically, the 2711P-T10C4A8 is a direct neighbour to the terminals it replaced, which is why it also makes a clean donor cutout for a PanelView Plus 7 migration. Your panel door owes its life to this one dimension.
