Product Overview
The Allen-Bradley 2711P-T7C4D8 is a PanelView Plus 6 700-series operator interface terminal manufactured by Rockwell Automation, delivering dependable machine-level visualization and control in a compact 6.5-inch touch-screen package. Equipped with a bright TFT color display operating at 640 × 480 VGA resolution with 18-bit color depth and a typical brightness of 300 nits, the terminal provides crisp graphical rendering of alarms, trends, setpoints, and process states directly at the point of operation. As a member of the PanelView Plus 6 family, the 2711P-T7C4D8 runs Windows CE 6.0 and is programmed through FactoryTalk View Machine Edition, giving integrators a consistent, scalable HMI development environment that spans from this 700-class terminal all the way up to 1500-series units.
Communication flexibility is a defining attribute of the 2711P-T7C4D8. The terminal integrates a standard 10/100Base-T Ethernet port with an RJ45 connector for EtherNet/IP connectivity to ControlLogix, CompactLogix, and Micro800 controllers, alongside an RS-232 serial port supporting DH-485, DF1, and Modbus-style master protocols for legacy SLC 500, PLC-5, and MicroLogix platforms. Two USB host ports round out the connectivity for keyboards, mice, printers, and removable media, while the modular PanelView Plus architecture — pairing the 2711P-RDT7C display module with the 2711P-RP8D logic module — allows either half to be serviced or upgraded independently in the field.
Engineered for the demands of continuous production environments, the 2711P-T7C4D8 carries a NEMA/UL Type 12, 13, and 4X (indoor) enclosure rating with IEC IP54/IP65 compliance, a T4 temperature code, and vibration, shock, and humidity tolerances aligned with industrial standards. With 512 MB of nonvolatile flash, 512 MB of RAM, a 1 GHz-class logic module processor, and support for ActiveX controls and web-browser-based remote monitoring, the 2711P-T7C4D8 delivers both the integration depth and the long-term serviceability that plant-floor stakeholders expect from the Allen-Bradley PanelView ecosystem.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 2711P-T7C4D8 / Series A (Rev. A) |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Product Type | Operator Interface Terminal (HMI) |
| Product Series | PanelView Plus 6, 700-Class Terminal |
| Display Size & Type | 6.5-inch TFT color LCD, active matrix |
| Display Resolution | 640 × 480 VGA, 18-bit color, 300 nits typical |
| Viewing Area | 132 × 99 mm (5.2 × 3.9 in) |
| Input Type | Resistive analog touch screen |
| Processor | 2711P-RP8D logic module, 1 GHz-class CPU |
| Memory | 512 MB nonvolatile Flash, 512 MB RAM |
| Operating System | Microsoft Windows CE 6.0 |
| Programming Software | FactoryTalk View Machine Edition (firmware 6.00–8.10) |
| Communication Ports | 1 × Ethernet 10/100Base-T (RJ45), 1 × RS-232 (DH-485 / DF1), 2 × USB host |
| Supply Voltage | 24 VDC (18 to 32 VDC isolated), 70 W maximum |
| Dimensions (H × W × D) | Approx. 254 × 178 × 76 mm (10.0 × 7.0 × 3.0 in) |
| Weight | 1.7 kg (3 lbs 11 oz) |
| Operating Temperature | 0 °C to +55 °C (32 °F to 131 °F), T4 code |
| Storage Temperature | −25 °C to +70 °C (−13 °F to 158 °F) |
| Relative Humidity | 5 % to 95 % non-condensing |
| Vibration / Shock | 10–57 Hz @ 0.012 mm p-p; 57–500 Hz @ 2 g; 15 g operating / 30 g non-operating |
| Enclosure Rating | NEMA/UL Type 12, 13, 4X (indoor); IEC IP54 / IP65 |
| Country of Origin | United States |
Main Features and Advantages
High-Visibility 6.5-inch Color Touch Display: The 2711P-T7C4D8 presents process graphics on a vibrant 6.5-inch TFT panel with 18-bit color depth and 640 × 480 VGA resolution, providing sharp text, vivid alarm banners, and legible trend curves even in brightly lit production areas. The resistive analog touch screen responds accurately to gloved-hand operation and supports multi-layer screen navigation, slider objects, and on-screen keyboard entry — eliminating the need for a separate keypad while keeping the operator interface ergonomic and intuitive.
Modular PanelView Plus Architecture: A distinctive strength of the 2711P-T7C4D8 is its two-piece modular construction. The 2711P-RDT7C display module can be detached from the 2711P-RP8D logic module, enabling independent replacement of a failing backlight, touch sensor, or logic board without swapping the entire terminal. This modularity also allows plants to upgrade compute capacity or migrate to newer PanelView Plus 7 logic modules while reusing existing display modules and panel cutouts — protecting prior capital investment and shortening maintenance windows.
Native Integration with Rockwell Control Platforms: Running FactoryTalk View Machine Edition under Windows CE 6.0, the 2711P-T7C4D8 connects directly to ControlLogix, CompactLogix, FlexLogix, MicroLogix, SLC 500, and PLC-5 families through its EtherNet/IP and serial interfaces. Alarm and event handling supports buffered, confirmed, and timestamped messaging; the terminal accepts up to 20 online runtime languages and integrates ActiveX controls for extended visualization objects, giving integrators a robust toolset for multi-lingual, multi-controller installations.
Industrial-Grade Environmental Hardening: Built to survive washdown-adjacent environments and control-room duty alike, the 2711P-T7C4D8 carries a NEMA/UL Type 12, 13, and 4X (indoor) rating together with IEC IP54/IP65 compliance. It tolerates vibration from 10 Hz to 500 Hz at up to 2 g acceleration, withstands 15 g operating shock, and operates reliably at altitudes up to 2,000 m, making it suitable for mounting on mobile machinery, on packaging lines, and in electrical rooms subject to thermal cycling.
Rich Expansion and Serviceability: The terminal exposes two USB host ports for keyboards, mice, and printers, and accepts the 2711P-T7C4D8-compatible 2711P-RN20 Ethernet module for adding a second, independently-addressed network port. Front-panel LED indicators report power, communication, and fault status, while firmware updates from version 6.00 through 8.10 can be applied over Ethernet or via CompactFlash — simplifying fleet-wide revision management across multi-terminal installations.
Application Field
The 2711P-T7C4D8 is deployed across an exceptionally broad spectrum of manufacturing and process industries wherever reliable machine-level operator interface is required. In discrete manufacturing — automotive sub-assembly, packaging machinery, palletizing cells, and assembly stations — the terminal provides the primary HMI for coordinating drives, robots, and I/O on the line, with the 6.5-inch touch screen offering ample real estate for line diagrams, batch controls, and alarm management without consuming valuable panel space.
In food & beverage, pharmaceutical, and consumer-goods plants, the 2711P-T7C4D8 is frequently specified for batch visualization, recipe selection, and quality-data entry on equipment such as fillers, mixers, weigh stations, and labeling machines, where its NEMA/UL Type 12, 13, and 4X (indoor) enclosure and non-condensing humidity tolerance support frequent wipe-down cleaning and washdown-adjacent mounting. The multi-language runtime support also makes the terminal well-suited to global OEM machines that ship to facilities operating in different languages.
Water/wastewater treatment, oil & gas, and power-generation facilities rely on the 2711P-T7C4D8 as a local operator interface for pumping stations, chemical-feed skids, compressor packages, and substation panels, where the combination of Ethernet/IP connectivity to ControlLogix processors and serial DH-485/DF1 support for legacy SLC and PLC-5 hardware allows the terminal to bridge modern and legacy control architectures within the same visualization layer.
Machine builders and system integrators favor the 2711P-T7C4D8 as a compact, cost-efficient HMI for OEM skid packages, test benches, and retrofit programs — particularly where an existing PanelView Plus installation must be extended or where a failed 2711P-T7C4D1 or 2711P-T7C4A8 unit needs a like-for-like replacement without reengineering the enclosure or FactoryTalk View application. As a result, the 2711P-T7C4D8 remains one of the most widely stocked and serviced PanelView Plus terminals in the global automation marketplace.
Related Products
2711P-T7C4A8 — Same 6.5-inch touch, Ethernet/RS-232 configuration as the 2711P-T7C4D8, but powered from 100–240 VAC instead of 24 VDC; commonly used where AC panel power is already available.
2711P-T7C4D1 — Earlier 6.5-inch touch/DC variant with 128 MB flash and 128 MB RAM, frequently replaced by the 2711P-T7C4D8 during memory or firmware upgrades.
2711P-T7C6D2 — 6.5-inch touch, DC-powered PanelView Plus 700 terminal with DH-485-focused communication for legacy SLC 500 and MicroLogix applications.
2711P-K7C4D8 — Keypad-input variant of the same 6.5-inch, Ethernet/RS-232, DC-powered terminal for operators preferring tactile key selection over touch.
2711P-B7C4D8 — Combined keypad + touch-screen 6.5-inch terminal providing both tactile function keys and on-screen interaction in the same panel cutout.
2711P-T10C4D8 — 10.4-inch touch/DC PanelView Plus 6 1000-class terminal with identical communication and power specifications, offering a larger display for more complex graphics.
2711P-RDT7C — 6.5-inch color touch display module; the front-end component of the 2711P-T7C4D8 that can be ordered or serviced independently.
2711P-RP8D — PanelView Plus 6 logic module (512 MB / 1 GHz-class CPU) that pairs with the 2711P-RDT7C to form the complete 2711P-T7C4D8 terminal.
2711P-RL7C2 — Replacement LED backlight module for the 2711P-RDT7C display, restoring full brightness when the original backlight reaches end of life.
2711P-RN20 — Optional Ethernet communication module that adds a second, independently-addressed 10/100Base-T port to the 2711P-T7C4D8 for redundant or segregated networking.
2711P-T7C22D9P — Suggested PanelView Plus 7 engineered replacement for the 2711P-T7C4D8, providing a modern 7-inch touch terminal with updated performance and longer lifecycle support.
