Product Overview
The 2711P-T6M20D8 is a 5.7-inch grayscale touchscreen operator terminal from the Allen-Bradley PanelView Plus 6 600 series, manufactured by Rockwell Automation. As a compact HMI solution within the PanelView Plus 6 family, the 2711P-T6M20D8 combines a monochrome TFT display with an analog resistive touchscreen and integrated Ethernet/RS-232 communication, running the Windows CE 6.0 operating system. This terminal is designed to provide operators with a reliable, cost-effective interface for monitoring and controlling automated machinery in space-constrained panel environments.
The 2711P-T6M20D8 occupies a specific position in the PanelView Plus 6 lineup as the DC-powered, grayscale touch model of the 600 series. The catalog number structure reveals its configuration: “T” indicates touchscreen-only input, “6” denotes the 5.7-inch display size, “M” signifies monochrome grayscale display technology, and “20” designates the Ethernet plus RS-232 communication option with USB ports. This configuration makes the 2711P-T6M20D8 particularly suitable for simple and small applications where color graphics are unnecessary but reliable communication and touch input are required.
It is important to note that Rockwell Automation has classified the 2711P-T6M20D8 as end-of-life (EOL). While no longer manufactured as a new product, the 2711P-T6M20D8 remains actively supported through the secondary market and surplus channels, serving as a critical spare part for facilities maintaining existing PanelView Plus 6 installations. Its compatibility with FactoryTalk View Machine Edition software version 6.10 or later ensures that existing HMI applications can continue to operate without modification when replacement units are deployed.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 2711P-T6M20D8 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Type | PanelView Plus 6 600 Operator Terminal |
| Display Size | 5.7 inches |
| Display Type | Grayscale TFT LCD, Monochrome |
| Resolution | 320 x 240 pixels, 16-level grayscale |
| Display Area | 115 x 86 mm |
| Brightness | 440 cd/m² |
| Touchscreen | Analog resistive, 4-wire, 1 million actuations rated |
| Input Voltage | 18–30V DC (24V DC nominal) |
| Power Consumption | 15W max (0.6A @ 24V DC), 9W typical |
| Memory | 256 MB RAM, 512 MB nonvolatile flash (~73–79 MB free user memory) |
| Communication | Ethernet (10/100 Mbps, Auto-MDI/MDI-X), RS-232 |
| USB Ports | 1 USB host, 1 USB device port |
| SD Card Slot | Hot-swappable, supports 1784-SDx SD cards |
| Operating System | Windows CE 6.0 |
| Software Support | FactoryTalk View ME v6.10+ |
| Backlight | White LED, non-replaceable, 25,000 hours min at 25°C |
| Real-Time Clock Battery | 2711P-RY2032 coin cell, 4-year min life at 25°C |
| Operating Temperature | 0°C to 55°C |
| Weight | Approximately 0.62 kg |
| Lifecycle Status | End-of-Life (EOL) |
Main Features and Advantages
Compact Footprint with Full HMI Capability: The 2711P-T6M20D8 delivers complete operator interface functionality within a 5.7-inch display format, making it ideal for small control panels and OEM equipment where panel space is at a premium. Despite its compact size, the terminal provides 320 x 240 pixel resolution across a 115 x 86 mm display area, sufficient for clear presentation of process values, alarm messages, and simple graphic representations. The analog resistive touchscreen, rated for one million actuations, offers reliable input without requiring a keyboard or function keys.
Integrated Ethernet and Serial Communication: The 2711P-T6M20D8 includes both Ethernet (10/100 Mbps with Auto-MDI/MDI-X) and RS-232 serial ports, providing flexibility in network architecture. Ethernet connectivity supports EtherNet/IP communication with Allen-Bradley controllers such as CompactLogix and ControlLogix, while the RS-232 port enables point-to-point or peer-to-peer communication using the DF1 protocol. This dual-interface design allows the 2711P-T6M20D8 to function in both modern networked architectures and legacy serial-based systems.
Windows CE 6.0 Platform with FactoryTalk View ME: The 2711P-T6M20D8 runs Windows CE 6.0 and ships with FactoryTalk View Machine Edition runtime preloaded and activated, enabling immediate deployment of HMI applications developed in the same environment used across the Rockwell ecosystem. This platform supports essential features including FTP server functionality, VNC client/server operation, PDF viewing, and ActiveX controls, providing a familiar development and runtime environment for engineers already working within the Allen-Bradley ecosystem.
Removable Storage and Peripheral Support: A hot-swappable SD card slot supports 1784-SDx cards for file transfers, firmware upgrades, and data logging without requiring network connectivity. Additionally, the 2711P-T6M20D8 provides one USB host port for connecting peripherals such as a mouse, keyboard, printer, or USB flash drive, and one USB device port for connecting to a host computer for programming or file transfer operations. These expansion options enhance the practical utility of the terminal in both commissioning and production contexts.
Application Field
The 2711P-T6M20D8 is deployed primarily in discrete and process automation applications where a compact, reliable interface is required for operator interaction with PLC-controlled machinery. In packaging machinery, the 2711P-T6M20D8 serves as the primary operator station for monitoring conveyor speeds, bagger cycles, and labeling system status, providing clear grayscale visualization of process parameters without the cost premium associated with color displays. The touchscreen interface allows operators to adjust setpoints and acknowledge alarms directly, streamlining workflows in fast-paced production environments.
Material handling systems utilize the 2711P-T6M20D8 for controlling sorters, palletizers, and automated storage and retrieval systems, where the terminal’s Ethernet connectivity enables seamless integration with ControlLogix or CompactLogix controllers. The monochrome display proves adequate for status indication and numeric data presentation, while the compact form factor allows installation in operator stations with limited panel real estate. In water and wastewater treatment facilities, the 2711P-T6M20D8 provides pump status visualization, tank level monitoring, and chemical dosing rate adjustment, with the grayscale display offering sufficient contrast for outdoor or brightly lit control rooms.
Food and beverage operations deploy the 2711P-T6M20D8 for managing simple batching processes and temperature profiles in wash-down areas, where the terminal’s panel-mount design with proper gasket compression maintains NEMA 4X/IP66 protection. OEM equipment manufacturers frequently select the 2711P-T6M20D8 as a cost-effective, durable interface for specialized industrial skids and standalone machines, benefiting from the terminal’s preloaded FactoryTalk View ME runtime and the broad availability of engineering resources within the Rockwell ecosystem. For facilities with existing PanelView Plus 6 installations, the 2711P-T6M20D8 remains an essential spare part, preserving operational continuity without requiring HMI application migration or panel redesign.
