Application Scenarios
A robotic palletizing cell built by a systems integrator for an appliance manufacturer required an operator station that could display cell status, allow manual jog control during maintenance, and log production counts without relying on a plant-wide network. The integrator specified the 2711PC-T10C4D1 alongside a GuardLogix controller and PowerFlex 525 drives, mounting it at the cell’s load station. During commissioning, the terminal’s Ethernet port connected directly to the controller for tag browsing during FactoryTalk View ME development, while the RS-232 port provided a fallback programming path when the plant network was not yet active. Once in production, the 10.4-inch display allowed operators to view the full pallet pattern and robot cycle status simultaneously—a significant improvement over the 6-inch terminal originally proposed, which would have required scrolling between screens during fault recovery. The integrator reported a 24% productivity increase within the first month of operation, attributed in part to faster operator response during jam-clearing sequences.
Parameter
| Parameter | Value/Description |
|---|---|
| Product Model | 2711PC-T10C4D1 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Category | PanelView Plus Compact 1000 touchscreen operator terminal |
| Display Type | 10.4-inch color active-matrix TFT |
| Resolution | 640 × 480 pixels (VGA) |
| Display Area | 211 × 158 mm (8.3 × 6.2 in.) |
| Operator Input | Resistive touchscreen |
| Operating System | Windows CE 6.0 |
| Communication | Ethernet (10/100 Mbps) and RS-232 |
| Input Power | 18–32 V DC |
| Memory (typical configuration) | 64 MB flash, 64 MB RAM |
| Enclosure Rating | NEMA Type 12, 13, 4X (indoor), IP54, IP65 |
| Operating Temperature | 0 to 55 °C (32 to 131 °F) |
| Programming Software | FactoryTalk View Studio (Machine Edition) |
| Lifecycle Status | Mature/legacy platform; PanelView Plus 6 Compact is the successor generation |
Key parameter notes: the “D1” suffix indicates DC power and standard communication configuration. The Compact series differs from full PanelView Plus models in that it ships with a fixed feature set and cannot accept certain add-on communication modules, so verify protocol requirements before specifying this model for ControlNet or DH+ networks.
Technical Principles and Innovative Values
- FactoryTalk View ME Runtime on Windows CE 6.0: The 2711PC-T10C4D1 executes applications developed in FactoryTalk View Studio for Machine Edition, the same engineering environment used across the PanelView Plus family. This means an application developed for this terminal can be ported to larger PanelView Plus 6 or 7 terminals with minimal rework, and tag databases built against Logix controllers use the same FactoryTalk Linx driver structure. For integrators maintaining mixed fleets of HMI sizes, this consistency reduces spare-parts complexity and training overhead.
- Resistive Touchscreen for Gloved and Wet Environments: Unlike capacitive touchscreens that require bare-skin contact, the resistive panel on the 2711PC-T10C4D1 responds to pressure from work gloves, styluses, or damp fingers. In food processing, cold storage, and wash-down areas where operators wear nitrile or cut-resistant gloves, this input method remains reliable where capacitive alternatives would require repeated taps or fail entirely. The IP65 front-panel rating supports this use case by sealing against directed water spray during cleaning.
- Compact Form Factor Without Sacrificing Screen Real Estate: The Compact 1000 series delivers a 10.4-inch display in a chassis that fits panel cutouts originally designed for smaller terminals. Compared with the 6-inch Compact models, the 2711PC-T10C4D1 provides 60% more display area, allowing operators to view alarm banners, trend windows, and control buttons simultaneously rather than navigating between screens. In applications where screen-switching during a fault costs seconds of diagnostic time, this additional area translates directly into faster recovery.
