Name: ABB 07AC91 Analog I/O Module – 8AI+8AO 12-Bit for Industrial Process Control - MASSIVE
SKU: ABB 07AC91-NEW

ABB 07AC91 Analog I/O Module – 8AI+8AO 12-Bit for Industrial Process Control

Brand ABB

Model ABB 07AC91-NEW

The ABB 07AC91 GJR5252300R0101 is a high-density analog input/output module designed for the ABB Advant Controller 31 (AC31) PLC platform, functioning as a remote I/O unit on the CS31 system bus. As a field-level interface component, the ABB 07AC91 GJR5252300R0101 bridges analog sensors and actuators with the central controller, providing both signal acquisition and output control within a single compact assembly. The module occupies a critical position in distributed control architectures, where it converts continuous process variables into digital data for controller processing while simultaneously driving analog final elements such as valves, dampers, and variable frequency drives.

The ABB 07AC91 GJR5252300R0101 operates in two selectable modes configured via DIP switches: a 12-bit mode providing 8 analog inputs plus 8 analog outputs, and an 8-bit mode supporting up to 16 channels configurable in pairs as input or output. This dual-mode architecture allows the ABB 07AC91 GJR5252300R0101 to adapt to different application requirements without hardware modification, matching legacy 4-20 mA instrumentation loops or newer voltage-based sensor configurations as needed. With 500 VDC galvanic isolation between channels, the module effectively suppresses ground loops and electrical noise from motors, variable frequency drives, and other industrial equipment, ensuring stable measurement accuracy in electrically harsh environments.

The ABB 07AC91 GJR5252300R0101 communicates with the AC31 controller over the CS31 serial bus using an RS-485 physical layer, supporting cyclic I/O exchange with 5-10 ms update rates suitable for closed-loop control applications. The module is housed in a DIN-rail mountable enclosure with pluggable screw terminals, front-mounted LED status indicators for each channel, and a test button for field diagnostics. As a discontinued ABB product, the ABB 07AC91 GJR5252300R0101 remains actively sought as a replacement part for existing AC31 and Advant OCS installations, where its continued availability supports the operational longevity of legacy control systems.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	ABB 07AC91 GJR5252300R0101
Manufacturer	ABB (ASEA Brown Boveri)
Product Type	Analog Input/Output Module (Remote I/O Unit)
Compatible Systems	ABB Advant Controller 31 (AC31 90 Series PLC), Advant OCS
Communication	CS31 System Bus (RS-485 physical layer)
Operating Mode 1 (12-bit)	8 analog inputs + 8 analog outputs, 12-bit + sign
Operating Mode 2 (8-bit)	Up to 16 channels configurable in pairs as input or output
Signal Ranges	±10 V, 0–10 V, 0–20 mA, 4–20 mA (per-channel configurable)
Resolution	12-bit or 8-bit selectable via DIP switches
Conversion Error	Typical 0.5%, maximum 1.0%
Isolation	500 VDC galvanic isolation between channels
Supply Voltage	24 V DC (19–30 V DC range)
Maximum Current Consumption	0.2 A
Maximum Power Dissipation	5 W
Analog Output Load	Maximum 500 Ω for current output
Input Impedance (Voltage)	100 kΩ
Operating Temperature	0°C to +55°C
Storage Temperature	-25°C to +75°C
Relative Humidity	10% to 90% RH, non-condensing
Protection Rating	IP20
Mounting	35 mm DIN rail (DIN EN 50022) or 4× M4 screws
Dimensions	Approximately 120 × 140 × 85 mm (W × H × D)
Weight	Approximately 0.45 kg (module)/0.81 kg (with terminals)
Terminal Type	Pluggable screw terminals, 0.08–1.5 mm² wire
Diagnostic Indicators	17 front-panel LEDs (power/ready + 16 channel diagnostics)
Address Setting	DIL coding switches under right-side cover
Programming Software	907 AC 1131 (IEC 61131-3)
Certifications	CE, ABS, CSA

Main Features and Advantages

The ABB 07AC91 GJR5252300R0101 distinguishes itself through a dual-mode architecture that provides exceptional application flexibility without requiring different hardware for varying signal-count requirements. In 12-bit mode, the module delivers high-accuracy conversion for 8 input and 8 output channels, while switching to 8-bit mode expands the total channel count to 16 with paired input/output configurability. This design decision enables the ABB 07AC91 GJR5252300R0101 to serve installations ranging from small process control loops to larger distributed I/O networks using a single spare part number.

Robust noise immunity through channel isolation: Each channel of the ABB 07AC91 GJR5252300R0101 incorporates 500 VDC galvanic isolation, a critical feature for installations where analog signals share cable trays or junction boxes with motor drives, contactors, and other noise-generating equipment. This isolation barrier prevents ground potential differences from corrupting measurement accuracy and protects the module’s internal circuitry from field-side transients. The result is stable, repeatable analog readings even in electrically demanding industrial environments.

Compact 16-channel density: The ABB 07AC91 GJR5252300R0101 achieves a channel density that significantly reduces I/O cabinet footprint compared to single-function analog cards. By combining both input and output functionality in one module, the design eliminates separate input and output module slots, associated wiring, and power distribution components. For system integrators and panel builders, this translates to smaller enclosures, reduced assembly time, and lower overall system cost.

Comprehensive field diagnostics: The ABB 07AC91 GJR5252300R0101 features front-panel LED indication for each of its 16 channels, providing immediate visual feedback on channel status including overload, wire break, and over-range conditions. A test button allows field technicians to verify channel functionality without removing the module from the DIN rail or disconnecting field wiring. Combined with CS31 bus diagnostic capabilities, these features minimize troubleshooting time and support efficient maintenance operations.
