ABB 5SGX2645L0001 6500V/2600A Press-Pack Thyristor for HVDC and Heavy Drives

Brand ABB

Model ABB 5SGX2645L0001 6500V/2600A

The ABB 5SGX2645L0001 is a high-power phase control thyristor module belonging to ABB’s 5SGX semiconductor series, built in a flat-plate press-pack (Press-Pack) package rated at 6500 V blocking voltage and 2600 A average on-state current. As a press-pack device, the ABB 5SGX2645L0001 contains no internal bond wires or solder joints — the silicon wafer is clamped between two ceramic-isolated copper electrodes under precisely specified clamping force, eliminating the wire-bond fatigue failure mode that eventually degrades conventional welded modules. This construction makes the ABB 5SGX2645L0001 the preferred choice for series-stacked rectifier applications where decades of uninterrupted operation are the design brief.

The ABB 5SGX2645L0001 delivers 45 kA surge current capability (10 ms half-wave, non-repetitive), allowing it to absorb grid transients and DC-side short-circuit currents while upstream protection operates. Its double-sided cooling architecture enables heat to flow out of both the anode and cathode faces into the clamping heat sinks, achieving a junction-to-case thermal resistance of just 0.008 K/W. This low thermal impedance keeps junction temperatures controllable even at full 2600 A continuous current, making the ABB 5SGX2645L0001 suitable for forced-air or deionized-water cooling stacks in high-density power conversion equipment.

Manufactured by ABB Semiconductors (now part of Hitachi Energy), the ABB 5SGX2645L0001 is engineered for the most demanding power electronics applications: HVDC converter valves, medium-voltage drive DC links such as the ACS 6000 series, electrolytic smelting rectifiers, and large synchronous motor excitation systems. As a critical “current gate” in mega-watt-class energy control systems, the ABB 5SGX2645L0001 plays a role where reliability directly determines plant availability — one flashover in a rectifier stack can trigger transformer damage and production loss measured in tens of thousands per hour.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	5SGX2645L0001
Manufacturer	ABB (Semiconductors, now Hitachi Energy)
Product Type	High-Power Phase Control Thyristor, Press-Pack
VDRM / VRRM	6500 V (repetitive off-state / reverse)
IT(AV)	2600 A (average on-state current)
ITSM (10 ms)	45,000 A (surge non-repetitive)
VGT (Gate Trigger)	3.5 V typical
Tj Operating	-40°C to +125°C
Rth(j-c)	0.008 K/W (junction-to-case, double-sided)
Package / Mount	Flat-plate press-pack, clamp-force mounted
Insulation Voltage	6 kV AC / 1 min (to heat sink/clamp)
Cooling Method	Forced air or deionized water
Weight	Approximately 4.5 kg
Typical Applications	HVDC valve segments, electrolytic rectifiers, large DC drives, synchronous motor excitation

Main Features and Advantages

Press-Pack Construction Eliminates Bond-Wire Fatigue: Traditional module thyristors use internal aluminum bond wires from the wafer to the terminal posts; these wires cyclically fatigue under thermal swing and eventually open, representing the number one wear-out mode in welded modules. The ABB 5SGX2645L0001 clamps the wafer directly between molybdenum/ceramic-composite electrodes under a defined clamping force, so there is literally no internal interconnect to fail. Press-pack thyristors also tend to fail short-circuit rather than open, keeping the string diagnosable and preventing hazardous open-circuit conditions in series stacks.

Double-Sided Cooling with 0.008 K/W Thermal Resistance: Both the anode and cathode plates of the ABB 5SGX2645L0001 are thermally active, allowing heat to flow out both faces into the clamping stack. This halves the effective thermal resistance compared to single-sided cooled devices, enabling the ABB 5SGX2645L0001 to sustain 2600 A continuous current with manageable junction temperatures even in high-ambient environments such as aluminum smelter potlines.

45 kA Surge Capability for Grid Transients: The ABB 5SGX2645L0001 is rated for 45 kA non-repetitive surge current (10 ms half-wave). In electrolytic rectifier and HVDC applications, this surge margin allows the thyristor to absorb commutation overshoot and DC-side faults while upstream circuit breakers react, preventing catastrophic valve section failures during grid disturbances.

6500 V Blocking for HVDC and Medium-Voltage Drives: With 6500 V repetitive peak off-state voltage, the ABB 5SGX2645L0001 provides comfortable margin for 4.16 kV AC secondary rectifier applications where peak inverse voltage including commutation overshoot approaches 5.9 kV. This rating also suits series-stacked configurations in HVDC valves and STATCOM thyristor levels.

Proven Long-Term Reliability in Critical Infrastructure: In a documented Nordic aluminum smelter retrofit, a stack of ABB 5SGX2645L0001 press-pack devices replaced welded modules that had averaged one flashover every 26 months. Three years post-retrofit, the plant reported zero thyristor-led forced outages on that line, demonstrating the long-term reliability advantage of press-pack construction in high-current rectifier service.
