Description
Application Scenarios:
A packaging machinery OEM builds a case-packer that has to talk to a CompactLogix for sequence control, a PowerFlex drive bank over EtherNet/IP, a separate skid controller for the glue system, and a plant historian — and the operator needs all of it on one screen at the machine. The Standard tier would cap the connection count and the trending the customer is asking for; the 2711P-T10C22D9P is the tier that does not. Two Ethernet ports mean the terminal sits as a DLR node on the machine ring instead of dangling off a single switch port — if one cable is cut during a rebuild, the ring heals and the operator does not lose sight of the line.
Six months later, the same OEM gets a call: the machine is down and the local operator cannot describe the fault. Because the 2711P-T10C22D9P carries a VNC server, the OEM’s support engineer connects remotely, sees the alarm banner and the process graphic exactly as the operator sees it, and talks the operator through the reset in minutes instead of dispatching a technician. Typical homes for the 2711P-T10C22D9P span packaging and bottling machinery, automotive assembly and weld cells, food and beverage process skids, pharmaceutical batch equipment, water and wastewater pump and filter stations, material handling and sortation, metals and general process plants, and OEM machinery where remote diagnostics and multi-controller visibility are part of the product. In all of them the value is the same: one screen that can see every controller on the machine, on a network that survives a single cable failure.
Parameter:
| Main Parameters | Value/Description |
|---|---|
| Product Model | 2711P-T10C22D9P (variants: -B brandless, -K conformal coated as 2711P-T10C22D9PK) |
| Manufacturer | Allen-Bradley / Rockwell Automation; UPC 885630844626 |
| Product Category | PanelView Plus 7 Performance graphic terminal — HMI operator interface with integrated Ethernet switch |
| Display Size / Type | 10.4-in diagonal colour active-matrix TFT LCD, 4:3 aspect ratio, viewing area 211 × 158 mm |
| Resolution / Colour | 800 × 600 SVGA — 18-bit colour graphics on Series A, 24-bit on Series B |
| Brightness | 300 cd/m² (nits) typical |
| Backlight | Solid-state white LED, 50,000 h minimum to half brightness at 40 °C — not replaceable |
| Touch Screen | Analog resistive, 1 million press actuation rating, 100 g operating force — works with gloves and stylus |
| System Memory (Series A) | 512 MB RAM / 512 MB storage, approx. 80 MB non-volatile user application memory |
| System Memory (Series B) | 4 GB RAM / 19.87 GB storage, approx. 2 GB non-volatile user application memory |
| Operating System | Series A: Windows CE 6.0 — Series B: Windows 10 IoT Core; both run the same FactoryTalk View ME applications |
| Ethernet Ports | Two 10/100Base-T with auto-negotiation, supporting DLR (Device Level Ring), linear and star topologies — embedded two-port switch |
| Serial Port | One RS-232 |
| USB Ports | Series A: 2 × USB 2.0 host + 1 × USB 2.0 device — Series B: 1 × USB 3.0 host + 1 × USB 2.0 host + 1 × device |
| SD Card Slot | One SD slot, hot-swappable; supported cards 1784-SD1 (1 GB), 1784-SD2 (2 GB), 1784-SDHC8 (8 GB), 1784-SDHC32 (32 GB) |
| Input Power | 24 V DC nominal, 18–30 V DC range, non-isolated; supports PELV and SELV supplies |
| Power Consumption | Series A: 50 W max (2.1 A at 24 V) — Series B: 29 W |
| Software | FactoryTalk View ME Station (pre-loaded, no activation required), FactoryTalk View Studio for Machine Edition, FactoryTalk ViewPoint (one embedded client licence) |
| Extended Features | VNC client and server, FTP and secure FTP server, ActiveX controls, third-party controller support, PDF reader, web browser, RDP client, media player, Office file viewers |
| Real-Time Clock | Battery-backed, ±2 minutes per month accuracy; CR2032 lithium coin cell (2711P-RY2032), 4-year minimum life at 25 °C |
| Enclosure Rating | NEMA Type 12, 13, 4X (indoor use); IP54 / IP66 front of panel |
| Operating Temperature | 0 °C to 55 °C; storage −25 °C to 70 °C; 5–95 % RH non-condensing |
| Physical Dimensions | Approx. 252 × 297 × 69.6 mm (9.92 × 11.69 × 2.74 in) — under 2 inches of cabinet depth |
| Weight | Approx. 2.28 kg (5.03 lb) |
| Certifications | UL Listed, CE, ATEX Zone 2/22, IECEx, KC, Australian RCM, EAC |
| Lifecycle Status | Active — current production, repairable/replaceable per Rockwell |
| Documentation | Technical Data 2711P-TD009; User Manual 2711P-UM008 |
