Description
Application Scenarios
On a food and beverage packaging line, changeover between product SKUs requires operators to select recipes, verify sensor readings, and acknowledge alarms—all from a single station mounted on the machine frame. The 2711P-T6C20D8 fits this role because its 5.7-inch color display remains readable under washdown lighting, and its analog resistive touchscreen accepts input through gloved hands, which capacitive screens often struggle to register . When the line’s PLC needs to push a new recipe, the terminal’s built-in Ethernet port (10/100 Mbps) delivers the data without additional gateway hardware, while the RS-232 port provides a fallback connection for legacy controllers or serial printers .
Parameter
| Parameter | Value/Description |
|---|---|
| Product Model | 2711P-T6C20D8 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Category | PanelView Plus 6 600 Operator Terminal |
| Display Size | 5.7 in. (145 mm) diagonal |
| Display Type | Color active-matrix TFT |
| Resolution | 320 × 240 pixels, 18-bit color |
| Touch Input | Analog resistive, 1 million presses rated |
| System Memory | 256 MB RAM, 512 MB nonvolatile (≈79 MB free user memory) |
| Communication Ports | 1 × Ethernet (10/100 Mbps), 1 × RS-232, 2 × USB host |
| Input Voltage | 18–30 VDC (24 VDC nominal) |
| Power Consumption | 15 W max (0.6 A @ 24 VDC) |
| Operating System | Windows CE 6.0 |
| Operating Temperature | 0°C to +55°C |
| Enclosure Rating | NEMA 4X/12/13, IP54/65 (front panel) |
| Mounting | Panel mount |
Technical Principles and Innovative Values
Innovation Point 1 — High-Performance Platform in a Compact Enclosure: The 2711P-T6C20D8 represents a significant generational leap over earlier PanelView Plus 600 terminals. Its processor speed increased from 350 MHz to 1 GHz, system RAM quadrupled from 64 MB to 256 MB, and flash storage grew from 64 MB to 512 MB . The practical effect is a screen transition rate approximately 70% faster than the previous model, meaning operators wait less between screens—a small but cumulative productivity gain across thousands of shift interactions.
Innovation Point 2 — Open Platform with Windows CE Flexibility: Unlike proprietary HMI terminals that lock users into a fixed feature set, the 2711P-T6C20D8 runs Windows CE 6.0, which supports FTP server functionality, third-party device drivers, and PDF file viewers . Maintenance technicians can transfer application files over the network without physically accessing the terminal, and the platform can host custom utilities that would be impossible on a closed system.
Innovation Point 3 — FactoryTalk View Integration from Day One: The terminal ships with FactoryTalk View Machine Edition station runtime preloaded and activated, meaning the 2711P-T6C20D8 is ready to load a runtime application as soon as it’s mounted and powered . For system integrators, this eliminates the firmware licensing step that often delays commissioning.
