Description
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 2711P-T7C4D9 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Series | PanelView Plus 6 |
| Product Type | Graphic Operator Terminal (HMI) |
| Display Size | 6.5 inches |
| Display Type | Color Active-Matrix TFT |
| Resolution | 640 x 480 pixels (18-bit color) |
| Display Area | 132 x 99 mm (5.2 x 3.9 in.) |
| Backlight | CCFL, 50,000 hours minimum at 25°C, field replaceable |
| Operator Input | Analog Resistive Touchscreen |
| Touch Actuations | Up to 1 million operations |
| Memory | 512 MB Flash / 512 MB RAM |
| Operating System | Windows CE 6.0 Extended |
| Communication Ports | Ethernet (10/100), RS-232 (DB9), 2x USB Host |
| Input Voltage | 18–30 VDC (Nominal 24 VDC) |
| Weight | Approx. 1.61–1.64 kg |
| Operating Temperature | 0°C to +55°C |
| Enclosure Rating | NEMA/UL Type 12, 13, 4X (Indoor), IEC IP54, IP65 |
| Certifications | c-UL-us (Class I Div 2 hazardous locations) |
Main Features and Advantages
Enhanced System Integration: The 2711P-T7C4D9 is engineered for seamless integration with Rockwell Automation’s Logix control platform, supporting direct browsing of Logix5000 controller addresses from FactoryTalk View Studio software. This native compatibility eliminates the need for complex tag mapping or middleware, allowing engineers to develop and deploy HMI applications more efficiently. The terminal’s FactoryTalk View ME software supports trending, expressions, data logging, animation, and multi-vendor communications, making the 2711P-T7C4D9 a versatile visualization solution for diverse automation environments .
Modular Hardware Architecture for Reduced Downtime: The 2711P-T7C4D9 separates the display module from the logic module, enabling field replacement of either component without discarding the entire terminal. If a logic board fails, the existing display and touch overlay remain in service; if the display is damaged, the logic module can be transferred to a new display unit. This modularity directly reduces mean time to repair and lowers the total cost of ownership over the terminal’s service life .
Extended Features and File Viewers: The “D9” suffix in the 2711P-T7C4D9 catalog number indicates that this terminal includes extended features and file viewers not available on standard models. Operators can access PDF documents directly on the terminal screen, enabling context-sensitive access to machine manuals, troubleshooting guides, and operation procedures without leaving the HMI application. The terminal also supports File Transfer Protocol (FTP), VNC remote access, and a built-in full Unicode font for multilingual applications .
Rugged Construction for Industrial Environments: The 2711P-T7C4D9 carries NEMA Type 12, 13, and 4X (indoor) enclosure ratings along with IEC IP54 and IP65 protection, making it suitable for panel-mount installation in environments where dust, moisture, and washdown conditions are present. The analog resistive touchscreen resists oil, grease, and chemical exposure while remaining responsive to gloved operator input, a critical requirement in food processing, packaging, and manufacturing applications .
