WOODWARD CSC3LG120 Control Module 24VDC for Industrial Automation

Brand WOODWARD

Model WOODWARD CSC3LG120-STOCK

The WOODWARD CSC3LG120 is a high-performance control module engineered for industrial automation, power generation, and engine management applications. As a versatile programmable logic controller within Woodward‘s control ecosystem, the WOODWARD CSC3LG120 combines advanced control algorithms with flexible I/O configurations and robust communication capabilities to deliver precise, reliable performance in demanding operational environments . The module is designed to handle complex control tasks ranging from turbine speed regulation to engine torque management and industrial process optimization.

In the architecture of modern industrial control systems, the WOODWARD CSC3LG120 serves as a central processing and control unit that interfaces seamlessly with sensors, actuators, and higher-level supervisory systems. Its support for PID control, feedforward control, and adaptive control algorithms enables the module to address diverse process requirements, from straightforward regulatory loops to dynamically changing operating conditions . The compact form factor and DIN rail mounting capability facilitate integration into both new installations and retrofit projects, while the wide operating temperature range of -40°C to +85°C ensures dependable operation across extreme industrial environments .

With certifications including CE and UL, the WOODWARD CSC3LG120 meets international standards for industrial safety and electromagnetic compatibility. Its modular design philosophy supports system scalability and simplifies maintenance procedures, making it a practical choice for power generation facilities, oil and gas operations, and manufacturing plants seeking a balance between performance, flexibility, and long-term reliability .

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	CSC3LG120
Manufacturer	Woodward
Product Type	Control Module / PLC Module
Supply Voltage	24 VDC
Power Consumption	5 W
Operating Temperature	-40°C to +85°C
Digital Inputs	16 channels
Digital Outputs	16 channels
Analog Inputs	4 channels (12-bit resolution)
Analog Outputs	4 channels (12-bit resolution)
Communication Protocols	CANbus, Modbus, Ethernet, RS-485
Dimensions	120 × 100 × 60 mm
Weight	1.2 kg
Certifications	CE, UL

Main Features and Advantages

The WOODWARD CSC3LG120 distinguishes itself through a combination of advanced control capability, communication flexibility, and industrial-grade durability that addresses the practical needs of system integrators and maintenance engineers.

Advanced Control Algorithm Integration: The WOODWARD CSC3LG120 incorporates PID control, feedforward control, and adaptive control capabilities within a single module platform. PID control handles conventional regulatory loops with proven stability, while feedforward control enables proactive compensation for measurable disturbances before they affect the process variable. Adaptive control further enhances performance by automatically adjusting parameters when operating conditions change, allowing the WOODWARD CSC3LG120 to maintain optimal control across varying load conditions and process dynamics .

Flexible Communication and I/O Configuration: Supporting CANbus and Modbus protocols alongside optional Ethernet and RS-485 interfaces, the WOODWARD CSC3LG120 integrates readily with Woodward control networks as well as third-party automation platforms. The module provides 16 digital inputs, 16 digital outputs, and four analog input and output channels with 12-bit resolution, offering substantial I/O capacity for medium-scale control applications without requiring additional expansion hardware .

Industrial-Grade Reliability: Engineered for continuous operation in challenging environments, the WOODWARD CSC3LG120 operates reliably across a temperature range of -40°C to +85°C. Its robust construction and component selection prioritize long-term stability, reducing unplanned downtime and maintenance frequency in critical applications .

Modular Design for Scalability: The WOODWARD CSC3LG120 follows a modular architecture that simplifies system expansion and component replacement. When control requirements grow or specific channels require servicing, the module can be reconfigured or replaced with minimal disruption to the broader control system, supporting efficient lifecycle management .
