2711p-t10c4a8_a_panelview_plus_6

Brand ABB

Model 2711p-t10c4a8_a_panelview_plus_6

Product Overview

The 2711P-T10C4A8 is a PanelView Plus 6 1000 operator terminal from Allen-Bradley, designed to deliver reliable machine and process visualization in industrial automation environments. As part of the PanelView Plus 6 family, the 2711P-T10C4A8 combines a 10.4-inch color active-matrix TFT display with an analog resistive touchscreen interface, providing operators with an intuitive platform for monitoring and controlling industrial processes . The terminal runs the Windows CE 6.0 operating system and supports FactoryTalk View Machine Edition software, enabling seamless integration with Allen-Bradley programmable logic controllers and other automation devices.

The 2711P-T10C4A8 features 512 MB of RAM and 512 MB of nonvolatile flash memory, sufficient capacity for complex HMI applications, data logging, and recipe management . Its 640 x 480 pixel resolution and 18-bit color graphics ensure clear, readable process displays with effective viewing area dimensions of 211 x 158 mm. The unit is powered by an external 100-240 VAC supply, making it suitable for deployment in control cabinets with standard AC power distribution .

This terminal has reached end-of-life status and is no longer manufactured by Rockwell Automation . The 2711P-T10C4A8 therefore serves as a sustainment solution for existing PanelView Plus 6 installations, where a failed terminal must be replaced with a compatible unit to preserve validated HMI applications and minimize production interruption. Its modular construction allows separate replacement of display, logic, and communication modules, extending serviceability across the terminal’s operational life .

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	2711P-T10C4A8
Manufacturer	Allen-Bradley / Rockwell Automation
Product Type	PanelView Plus 6 1000 Operator Terminal
Display Size	10.4 inches
Display Type	Color Active-Matrix TFT
Resolution	640 x 480 pixels, 18-bit color
Touchscreen Type	Analog Resistive (8-wire)
Touch Actuation	1 million presses, 10–110 g force
Memory	512 MB RAM / 512 MB Flash
Operating System	Windows CE 6.0
Input Voltage	100–240 VAC, 50–60 Hz
Power Consumption	160 VA maximum
Communication Ports	Ethernet (RJ45), RS-232 (9-pin Sub-D), 2 × USB Host
Backlight	CCFL, 50,000 hours minimum, field-replaceable
Real-Time Clock	Battery-backed, 4-year minimum battery life
Operating Temperature	0°C to 55°C
Enclosure Rating	Panel-mounted, NEMA Type 12/13/4X (indoor)
Weight	Approximately 3.18 kg (7.0 lbs)
Lifecycle Status	End of Life

Main Features and Advantages

Modular architecture for targeted maintenance: The 2711P-T10C4A8 is constructed with separate display, logic, and communication modules that can be replaced independently . This design reduces repair costs and downtime when a single component fails, as the entire terminal does not require replacement. The field-replaceable CCFL backlight further extends service life by allowing lamp replacement without terminal exchange .

Flexible communication for diverse control environments: The 2711P-T10C4A8 provides integrated Ethernet, RS-232, and dual USB ports as standard, supporting EtherNet/IP and DF1/DH-485 protocols . Optional communication modules accommodate DH+, DH-485, and ControlNet networks, allowing the terminal to interface with both modern and legacy Allen-Bradley control systems without external gateways .

Windows CE 6.0 open platform: The 2711P-T10C4A8 runs Windows CE 6.0, providing access to file transfer protocol, VNC remote access, PDF viewing, and ActiveX controls . This open environment enables advanced HMI functionality beyond basic display and control, including remote diagnostics and integration with third-party software applications.

Durable touchscreen interface: The 8-wire analog resistive touchscreen on the 2711P-T10C4A8 is rated for one million actuations with an operating force of 10–110 grams . This technology responds reliably to finger and gloved-hand input, making the 2711P-T10C4A8 suitable for production environments where operators may wear protective equipment.
