Description
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 2711P-T10C4D1 |
| Manufacturer | Rockwell Automation (Allen-Bradley) |
| Product Type | Operator Interface Terminal / HMI (Touch Screen) |
| Series / Platform | Allen-Bradley PanelView Plus 6 (2711P), 1000 Series |
| Display Size | 10.4 inch diagonal color TFT |
| Display Resolution | 800 × 600 pixels (SVGA), 18-bit color graphics |
| Touch Screen | Analog resistive touch, touch-only input (no keypad) |
| Input Power | 18 to 32 V DC (24 V DC nominal), DC-powered variant |
| Power Consumption | Approximately 50 W maximum (typical 25 W in operation) |
| Processor / Performance | PanelView Plus 6 class processor with increased performance over previous generations |
| Memory | 512 MB RAM / 512 MB non-volatile storage (PanelView Plus 6 class), plus internal application storage |
| Communication Ports | 10/100 Mbps Ethernet (RJ45), RS-232 serial port, USB 2.0 host port and USB device port |
| Supported Protocols | EtherNet/IP, DH-485, DF1, Modbus (via third-party drivers), plus direct drivers for Allen-Bradley controllers |
| Configuration Software | FactoryTalk View Studio for Machine Edition (FTView ME), versions compatible with PanelView Plus 6 firmware |
| Operating System | Microsoft Windows CE 6.0 (PanelView Plus 6 platform) |
| Real-Time Clock | Battery-backed clock with date and time functions |
| Expansion | Compatible with optional communication and memory expansion modules on PanelView Plus 6 variants |
| Front Bezel Rating | NEMA Type 12, 13, 4X (indoor use only); IP66 / IEC IP66 front panel when properly mounted |
| Agency Certifications | UL, cUL, CE, C-Tick, marine agency approvals available on select configurations |
| Panel Cutout | Approximately 259 × 196 mm (10.20 × 7.72 in) for the 1000 series form factor |
| Approximate Dimensions (H × W × D) | Approximately 282 × 223 × 68 mm |
| Approximate Weight | Approximately 2.7 kg (depending on configuration) |
| Operating Temperature | 0 °C to +55 °C (32 °F to 131 °F) |
| Storage Temperature | -25 °C to +70 °C |
| Relative Humidity | 5% to 95%, non-condensing |
| Mounting | Panel mount with mounting clips or studs; requires panel cutout and gasket sealing for NEMA rating |
Main Features and Advantages
Clear, responsive operator interface: The 10.4-inch color TFT display on the 2711P-T10C4D1 provides 800 × 600 SVGA resolution with 18-bit color depth, which is more than enough resolution to present detailed process graphics, multi-line alarm banners, recipe screens and trending windows without the cramped appearance of smaller terminals. Because the terminal uses analog resistive touch, operators can work with gloves, a stylus or a bare finger, and the touch target areas can be sized flexibly by the application developer. The result is an interface that reduces both operator error and training time, and lets a single screen replace dozens of physical devices.
Flexible multi-protocol connectivity: The 2711P-T10C4D1 ships with an integrated 10/100 Mbps Ethernet port, an RS-232 serial port and both USB host and USB device ports, so it can be commissioned into almost any Rockwell-based architecture without add-on communication cards. Over Ethernet, it communicates natively with ControlLogix and CompactLogix controllers using EtherNet/IP, and it can be networked with programming workstations, historians and supervisory systems on the same plant network. The RS-232 port supports DF1 and DH-485 connections to legacy SLC 500 and MicroLogix controllers, which makes the 2711P-T10C4D1 a practical upgrade path for older PanelView Standard and PanelView 550/600/900/1000 installations where serial remains the only path.
FactoryTalk View integration and fast application deployment: Because the 2711P-T10C4D1 is configured with FactoryTalk View Studio for Machine Edition and runs under Windows CE 6.0, development work is shared across the entire PanelView Plus family and reuses tags, graphics and alarms from the controller project. Applications are downloaded over Ethernet or USB, stored in internal non-volatile memory, and can be transferred to a replacement unit of the same catalog number, which allows maintenance teams to keep a pre-loaded spare on the shelf. Alarm handling, data logging, recipe management, runtime language switching and trends are all supported natively, so the terminal covers most machine HMI requirements without custom development.
Industrial packaging and serviceability: The front bezel of the 2711P-T10C4D1 is rated for NEMA Type 12, 13 and 4X indoor use and IP66 when mounted on a flat, sealed panel surface, so the terminal tolerates washdown-adjacent environments, dust and oil mist without a separate enclosure. The DC power input accepts anything from 18 to 32 V DC, tolerating the sags and ripple common in machine panels, and the battery-backed real-time clock keeps alarm and event time stamps accurate. Mounting uses standard clips or studs in a conventional cutout, and the entire terminal can be replaced from the front without disturbing the enclosure, which keeps changeover time measured in minutes.
