Description
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 3HNP04014-1 |
| Manufacturer | ABB Robotics (Sweden) |
| Product Type | LCD Display Module (LCM, Open Frame with Backlight) |
| Compatible Systems | ABB IRC5 FlexPendant, IRC5 BU w Touch cabinet panel |
| Display Technology | TFT Color LCD with LED backlight |
| Screen Size | 4.3 inches (typical) |
| Resolution | 480 × 272 pixels (mainstream version) |
| Brightness | 500–700 cd/m² (varies by production batch) |
| Backlight Lifespan | Approximately 50,000 hours (LED version) |
| Interface Type | ABB-customized ribbon cable (non-standard VGA/HDMI) |
| Supply Voltage | 5 V / 12 V / 24 V DC (provided by host panel board) |
| Power Consumption | ≤ 3 W typical |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | Approximately 148 × 107 × 8 mm |
| Weight | Approximately 0.16 kg |
| Mounting Type | Open-frame panel mount, screw fixing + ribbon cable latch |
| Replacement Compatibility | Direct replacement for 3HNP00005-1 |
Main Features and Advantages
Direct Replacement Compatibility: The ABB 3HNP04014-1 serves as the manufacturer-designated replacement for the legacy 3HNP00005-1 display unit, maintaining mechanical pin compatibility and identical physical mounting dimensions. This drop-in form factor eliminates the need for wiring modifications or adapter brackets during field replacement.
Industrial-Grade Display Performance: The ABB 3HNP04014-1 delivers high-brightness output reaching 500–700 cd/m², ensuring clear readability under diverse ambient lighting conditions commonly encountered in manufacturing floors and industrial control rooms. The LED backlight technology provides consistent illumination throughout the module’s operational lifespan of approximately 50,000 hours.
Custom ABB Interface Architecture: Unlike generic industrial TFT displays using standard RGB or LVDS interfaces, the ABB 3HNP04014-1 employs an ABB-customized ribbon cable pinout that connects directly to the FlexPendant or BU w Touch mainboard. This proprietary interface ensures seamless communication with the host controller without requiring firmware modifications or signal conversion.
Robust Environmental Protection: The ABB 3HNP04014-1 operates reliably across a temperature range of -20°C to +60°C and withstands humidity levels from 5% to 95% non-condensing. The module’s construction protects internal display driver circuits against high-frequency electronic noise generated by nearby drive converters and robot motion controllers.
Maintenance-Optimized Design: The ABB 3HNP04014-1 enables targeted repair of display failures—backlight dimming, pixel defects, or physical screen damage—without replacing the entire FlexPendant or operator panel assembly. For facilities operating multiple IRC5 robot cells, maintaining the ABB 3HNP04014-1 as a critical spare significantly reduces mean time to repair for HMI failures.
