Allen-Bradley 1336S-EN4 Language Module – English Interface for 1336 PLUS AC Drives

Brand ABB

Model Allen-Bradley 1336S-EN4

Product Overview

The Allen-Bradley 1336S-EN4 is an English language module engineered specifically for the Allen-Bradley 1336 series of adjustable frequency AC drives, including the 1336 PLUS, PLUS II, FORCE, and REGENT product lines. This module serves as a critical interface component that provides English language support for the drive’s human-machine interface (HIM), enabling operators and technicians to navigate programming menus, interpret fault codes, and monitor system status in clear English text. Without a functional language module installed, the 1336 drive series cannot operate correctly, as the module is responsible for translating internal signals and programming options into a readable format.

The Allen-Bradley 1336S-EN4 functions as an insertable chip-based module that mounts directly onto the drive’s main control board via an edge connector interface. This compact form factor allows for straightforward installation and replacement without requiring specialized tools or extensive disassembly. The module contains firmware version 4.02EN4 and supports English/English language configuration, meaning both the primary and alternate language settings are fixed to English—a design feature that prevents accidental language switching in facilities where operators rely exclusively on English interfaces.

As a discontinued but still widely supported component, the Allen-Bradley 1336S-EN4 remains essential for maintaining legacy 1336 drive systems in operational condition. The module’s presence is mandatory for drive functionality; without it, the drive cannot display programming parameters or diagnostic information, effectively rendering the unit unusable. For facilities operating 1336 PLUS and related drive platforms, the Allen-Bradley 1336S-EN4 represents a critical spare part that ensures continued operation and minimizes downtime risk.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	1336S-EN4 (42336-224-51)
Manufacturer	Allen-Bradley (Rockwell Automation)
Product Type	Language Module Kit
Product Family	1336 PLUS Adjustable Frequency AC Drives
Compatible Drive Series	1336 PLUS, PLUS II, FORCE, REGENT
Language Configuration	English/English
Firmware Version	4.02EN4
Mounting Type	Internal plug-in on main control board
Connection Interface	Edge connector
Operating Temperature	0°C to 50°C (ambient air)
Dimensions	19.2 cm x 16.5 cm x 2.5 cm
Weight	0.24 kg
Country of Origin	USA
Lifecycle Status	Discontinued / Obsolete

Main Features and Advantages

The Allen-Bradley 1336S-EN4 provides essential language interface capabilities that directly impact drive operability and maintenance efficiency.

Mandatory Operational Component: The Allen-Bradley 1336S-EN4 is not an optional accessory—it is a required component for any 1336 series drive to function. Without the language module installed, the drive cannot translate internal signals into readable text, leaving operators unable to access programming parameters or interpret diagnostic codes. This makes the Allen-Bradley 1336S-EN4 one of the most critical spare parts for maintaining legacy 1336 drive systems.

English Language Lock Feature: The Allen-Bradley 1336S-EN4 is configured as an English/English module, meaning both the primary and alternate language parameters are fixed to English. This design prevents operators from inadvertently switching the interface to a foreign language, which could cause confusion in facilities where English is the standard operating language. The language lock ensures consistent interface presentation across all shifts and personnel.

Straightforward Installation Process: Installing the Allen-Bradley 1336S-EN4 requires no specialized programming or configuration tools. The module snaps directly onto the drive’s main control board using a silk-screen outline as a positioning guide. Once seated, the module locks in place and the drive recognizes it automatically. After installation, a simple parameter reset and fault clear restores normal operation.

Legacy System Support: As the 1336 drive platform has been discontinued, the Allen-Bradley 1336S-EN4 provides a critical pathway for extending the service life of existing installations. Facilities can maintain their current drive infrastructure without incurring the substantial costs associated with full system migration.
