Description
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | Bently Nevada 3300/53-03-01-00-50-06-01-00-00 |
| Manufacturer | Bently Nevada |
| Product Type | Modular Plug-In Connector |
| Compatible Module | 3300/53 Overspeed Protection Module |
| System Platform | 3300 Monitoring System |
| Material | High-Grade Brass and Durable Plastic |
| Rated Current | 25 A |
| Voltage Rating | AC 600V / DC 300V |
| Operating Temperature | -40°C to +85°C |
| Insulation Resistance | ≥1000 MΩ |
| Connection Type | Quick-Disconnect |
| Number of Contacts | 5 |
| IP Rating | IP67 |
| Certifications | CE, UL |
| Mounting | Rack Backplane Interface |
Main Features and Advantages
The Bently Nevada 3300/53-03-01-00-50-06-01-00-00 connector delivers the reliability and performance characteristics essential for critical machinery protection applications.
High-Grade Construction for Long-Term Reliability: The Bently Nevada 3300/53-03-01-00-50-06-01-00-00 is manufactured from high-grade brass with durable plating, ensuring superior electrical conductivity and resistance to corrosion even in harsh industrial environments. This construction quality directly supports the high-integrity signal paths required by the 3300/53 Overspeed Protection Module, which relies on accurate input signals to make safety-critical trip decisions.
Quick-Disconnect Modular Design: The connector features a quick-disconnect mechanism that enables rapid module replacement without the need for specialized tools. This design philosophy is particularly valuable in the 3300 Series architecture, where minimizing downtime during maintenance activities is a primary operational objective. Technicians can remove and replace the overspeed protection module efficiently, reducing the window during which machinery protection functions are unavailable.
Superior Environmental Protection: With an IP67 rating, the Bently Nevada 3300/53-03-01-00-50-06-01-00-00 connector is protected against dust ingress and temporary immersion in water. The operating temperature range of -40°C to +85°C ensures stable performance across the diverse environmental conditions encountered in power plants, refineries, and industrial facilities worldwide.
Electrical Performance for Critical Signals: The connector’s high insulation resistance of ≥1000 MΩ and low contact resistance minimize signal loss and preserve data integrity during transmission. This electrical performance is essential for maintaining the accuracy of overspeed detection signals, where even minor signal degradation could compromise the module’s ability to detect dangerous conditions accurately.
