Description
Application Scenarios
In a commercial building automation system managing HVAC, lighting, and energy subsystems across multiple floors, controllers must communicate seamlessly to maintain occupant comfort and optimize energy consumption. The HONEYWELL 10014/H/I functions as the communication backbone within each Excel 50 controller, storing system firmware in its Flash EPROM and facilitating peer-to-peer data exchange between controllers on the LonMark™ network. When facility managers needed to upgrade the control algorithms across the entire building without replacing hardware, the 10014/H/I module enabled firmware updates via simple download, avoiding costly controller swaps and minimizing system downtime.
Parameter
| Parameter | Value/Description |
|---|---|
| Product Model | HONEYWELL 10014/H/I |
| Manufacturer | Honeywell |
| Product Category | Communication Module / Dual Port EPROM Flash Memory |
| Input Channels | Up to 16 |
| Nominal Voltage | 115 VAC |
| Current Range | 4-15 mA |
| Power Requirements | 5 Vdc @ 35 mA; 24 Vdc @ 35 mA |
| Memory Type | Flash EPROM |
| Network Compatibility | LonMark™ Network Variables (V.3.0) |
| Operating Temperature | -20°C to +55°C |
| Humidity Range | 0% to 95% RH (non-condensing) |
| Dimensions | 4 cm × 18.4 cm × 12.8 cm |
| Weight | 0.3–0.34 kg |
Technical Principles and Innovative Values
- Innovation Point 1 – Flash EPROM Architecture for Field Upgrades: The HONEYWELL 10014/H/I stores system firmware in Flash EPROM, a design choice that enables straightforward operating system upgrades via download rather than physical chip replacement. This approach extends the operational lifespan of the host controller and allows facilities to adopt new features without hardware obsolescence.
- Innovation Point 2 – LonMark™ Interoperability: The module supports standard LonMark™ Network Variables in accordance with Interoperability Guidelines V.3.0, ensuring seamless integration with other LonMark-certified devices regardless of manufacturer. This interoperability reduces integration complexity and future-proofs building and industrial automation investments.
- Innovation Point 3 – Peer-to-Peer Communication Capability: The 10014/H/I enables direct controller-to-controller communication, allowing multiple Excel 50 controllers to be linked and accessed in larger-scale applications. This distributed architecture eliminates single points of failure and supports scalable system expansion without central bottlenecks.
- Innovation Point 4 – Integrated I/O Support: The module supports up to 22 integrated I/Os within the Excel 50 platform, consolidating communication and control functions into a unified hardware solution. This integration reduces cabinet space requirements and simplifies wiring in dense automation installations.
