Honeywell 10020/1/2 FSC CPU Module for Burner Management and ESD Applications

Brand Honeywell

Model Honeywell 10020/1/2

Product Overview

The Honeywell 10020/1/2 is a high-reliability central processing unit module designed for Honeywell‘s Fail Safe Controller (FSC) systems, forming the computational core of safety instrumented system architectures. As a quad-processor module, the Honeywell 10020/1/2 executes safety-critical logic, manages diagnostic routines, and coordinates communication across the FSC backplane with fault-tolerant precision. This CPU module is integral to the Experion PKS platform and is deployed in applications where failure is not an option.

The 10020/1/2 Honeywell features a quad-processor architecture that enables simultaneous execution of multiple control tasks, supporting the high-integrity safety functions demanded by emergency shutdown systems, burner management, and fire and gas detection networks. Its 128 Kbytes of system RAM accommodates all I/O, markers, counters, timers, and up to 7 Kbytes of register space, while an additional 128 Kbytes of application RAM allows small application programs to run directly in RAM without requiring supplementary memory circuits in the dual in-line sockets.

Functionally, the Honeywell 10020/1/2 serves as the decision-making hub of the FSC system, processing field input data, executing protection interlocks, and generating output commands to actuators and shutdown devices. Its fail-safe design ensures that in the event of a power failure or detected internal fault, the module transitions to a predetermined safe state, preventing catastrophic process failures and protecting plant personnel and equipment. For facilities operating legacy FSC installations, the 10020/1/2 Honeywell represents the critical processing layer that maintains safety integrity across the entire control loop.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	Honeywell 10020/1/2
Manufacturer	Honeywell
Product Type	FSC CPU Module / Quad Processor Module
System Family	Fail Safe Control (FSC)
Processor Architecture	Quad independent processors
System RAM	128 Kbytes (I/O, markers, counters, timers, registers)
Application RAM	128 Kbytes (jumper-selectable)
Register Space	Up to 7 Kbytes
Power Requirements	5 Vdc, 24 Vdc internal, 24 Vdc external
Output Channels	8 (24 Vdc solid-state source, short-circuit proof)
Operating Temperature	0°C to +60°C
Storage Temperature	-40°C to +85°C
Relative Humidity	5% to 95% RH, non-condensing
Dimensions	120 × 80 × 40 mm (approx.)
Weight	0.14 kg (140 g)
Country of Origin	USA
Certifications	CE, UL508, CSA compliant

Main Features and Advantages

Quad-Processor Fault Tolerance: The Honeywell 10020/1/2 employs four independent processors operating in a fault-tolerant configuration, enabling simultaneous execution of safety logic, diagnostics, and communication tasks. This architecture ensures that a single processor fault does not compromise system operation, maintaining safety integrity in the most demanding industrial environments.

Comprehensive Safety Diagnostics: The 10020/1/2 Honeywell executes continuous self-diagnostic routines that monitor processor health, memory integrity, and internal bus communication. Any detected anomaly triggers immediate fault indication, allowing maintenance personnel to respond before safety function degradation occurs. The module‘s front-panel status LEDs provide clear operational feedback for rapid troubleshooting.

Fail-Safe Design Philosophy: Built specifically for safety instrumented systems, the Honeywell 10020/1/2 transitions to a predetermined safe state upon detection of critical faults or power loss. This fail-safe behavior is fundamental to the FSC architecture, ensuring that the controlled process enters a protective condition rather than an indeterminate state during abnormal events.

Flexible Memory Configuration: With 128 Kbytes of system RAM and an additional 128 Kbytes of jumper-selectable application RAM, the 10020/1/2 Honeywell provides sufficient capacity for complex safety logic without external memory expansion. This onboard memory architecture simplifies system design and reduces potential failure points associated with external memory circuits.

Experion PKS Integration: The Honeywell 10020/1/2 integrates seamlessly with the Experion Process Knowledge System platform, enabling unified safety and process control architectures. This compatibility allows operators to monitor FSC system status alongside regulatory control data, streamlining plant operations and maintenance workflows.
