Name: Oriental Motor 4IK60A-BF-E10 Induction Motor – 60W Three-Phase with Electromagnetic Brake - MASSIVE
SKU: Oriental 4IK60A-BF-E10

Oriental Motor 4IK60A-BF-E10 Induction Motor – 60W Three-Phase with Electromagnetic Brake

Brand ABB

Model Oriental 4IK60A-BF-E10

The Oriental Motor 4IK60A-BF-E10 is a 60W three-phase induction motor from the World K Series, factory-assembled with a parallel shaft gearhead and a power-off activated electromagnetic brake. As a combination unit, the Oriental Motor 4IK60A-BF-E10 delivers integrated speed reduction, torque multiplication, and fail-safe load holding in a single compact package. The model designation “BF” indicates the built-in electromagnetic brake, while “E10” specifies the 10:1 gear ratio.

Positioned for uni-directional continuous operation, the Oriental Motor 4IK60A-BF-E10 is engineered for conveyor systems, packaging machinery, and material handling equipment where reliable, quiet performance is essential. The World K Series platform provides global voltage compatibility, overheat protection, and compliance with major international safety standards . The Oriental Motor 4IK60A-BF-E10 integrates motor, gearhead, and brake at the factory, eliminating alignment errors and simplifying installation for equipment manufacturers.

The electromagnetic brake in the Oriental Motor 4IK60A-BF-E10 operates on a power-off activation principle: when power is removed, the brake engages instantly and holds the load in position . This fail-safe characteristic makes the Oriental Motor 4IK60A-BF-E10 particularly suited for vertical applications and emergency stop scenarios. The 10:1 parallel shaft gearhead reduces the motor‘s rated speed to 150 rpm at 50 Hz or 180 rpm at 60 Hz, delivering higher torque at the output shaft for demanding load requirements.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	Oriental Motor 4IK60A-BF-E10
Manufacturer	ORIENTAL MOTOR Co., Ltd.
Product Type	Three-Phase Induction Motor with Electromagnetic Brake and Gearhead
Product Series	World K Series / K Series
Rated Output Power	60 W
Power Supply Voltage	Three-Phase 200 VAC
Rated Frequency	50/60 Hz
Gear Ratio	10:1 (E10 designation)
Output Shaft Speed	150 rpm (50 Hz) / 180 rpm (60 Hz)
Brake Type	Power-Off Activated Electromagnetic Brake
Brake Function	Fail-Safe Load Holding
Overheat Protection	Thermal Protector (Automatic Return)
Insulation Class	Class E (120°C)
Operating Ambient Temperature	-10°C to +50°C (Non-Freezing)
Operating Ambient Humidity	85% Maximum (Non-Condensing)
Dimensions	6.2 cm × 38.6 cm × 17.3 cm
Weight	2.62 kg

Main Features and Advantages

Integrated Motor-Gearhead-Brake Assembly: The Oriental Motor 4IK60A-BF-E10 arrives fully assembled and factory-aligned, eliminating the separate procurement and assembly steps required for motor, gearhead, and brake components. This integrated design reduces inventory complexity, shortens equipment build time, and removes alignment errors that can cause vibration and premature failure. The Oriental Motor 4IK60A-BF-E10 is ready for installation directly from the box.

Fail-Safe Electromagnetic Brake: The power-off activated brake in the Oriental Motor 4IK60A-BF-E10 engages automatically when power is interrupted, instantly stopping the motor and holding the load in position . This characteristic is essential for vertical applications such as lifts and hoists, where gravity would otherwise cause load drift. The brake also functions as an emergency stopping mechanism, providing an additional layer of safety beyond normal motor control.

Optimal for Uni-Directional Continuous Operation: Induction motors like the Oriental Motor 4IK60A-BF-E10 are specifically designed for continuous uni-directional running, making them ideal for conveyor systems and similar applications where the motor operates in one direction for extended periods . The robust construction and thermal protection ensure reliable performance in sustained operation.

Quiet and Durable Gearhead Design: The parallel shaft gearhead in the Oriental Motor 4IK60A-BF-E10 uses precision-machined gears for smooth, quiet operation. The 10:1 reduction ratio delivers the speed-torque characteristics required for moderate-speed material handling tasks. The compact frame size allows integration into space-constrained equipment layouts.
