3300_35-13-01-01-00-02_bently_nevada_6_channel_temperature_monitor

Brand Allen-Bradley

Model 3300_35-13-01-01-00-02_bently_nevada_6_channel_temperature_monitor

Product Overview

The 3300/35-13-01-01-00-02 is a six-channel temperature monitor module from Bently Nevada, designed for integration within the 3300 Series Machinery Protection System. As a dedicated component of the 3300 rack architecture, the 3300/35-13-01-01-00-02 provides continuous, independent temperature monitoring across six channels, enabling early detection of overheating conditions in critical rotating equipment such as turbines, compressors, and large motors. The module accepts inputs from resistance temperature detectors and thermocouples, converting thermal signals into alarm evaluation and proportional output signals for external systems.

The model number 3300/35-13-01-01-00-02 encodes a specific configuration. The “13” indicates a 0–200°C full-scale range, while the first “01” specifies 100 Ω platinum RTD input with an alpha of 0.00392 (3-wire configuration). The second “01” denotes epoxy-sealed alarm relays, providing Alert and Danger setpoint annunciation. The “00” signifies that no specific agency approval option was ordered, and the final “02” indicates internal safety barriers are included, making the 3300/35-13-01-01-00-02 suitable for installations requiring intrinsic safety protection in hazardous areas.

The 3300/35-13-01-01-00-02 operates within the Bently Nevada 3300 platform, a long-established machinery protection architecture widely deployed in power generation, oil and gas, and heavy industrial facilities. While newer Bently Nevada platforms such as the 3500 series have been introduced, the 3300 series remains in active service globally, and the 3300/35-13-01-01-00-02 serves as a sustainment solution for existing installations requiring compatible replacement modules.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	3300/35-13-01-01-00-02
Manufacturer	Bently Nevada (GE)
Product Type	Six-Channel Temperature Monitor
Compatible System	3300 Series Machinery Protection Rack
Input Channels	6 independent RTD channels
Sensor Input Type	100 Ω platinum RTD, α = 0.00392, 3-wire
Full-Scale Range	0–200°C (Option 13)
Alarm Relay Option	Epoxy-sealed (Option 01)
Safety Barrier Option	Internal (Option 02)
Alarm Setpoints	Alert and Danger, digitally adjustable
Output Types	4–20 mA, 1–5 VDC, 0 to –10 VDC
Output Impedance	100 Ω (voltage outputs)
Voltage Compliance	0 to +12 VDC (current outputs)
Power Consumption	Nominal 4 W
Operating Temperature	0°C to +65°C
Storage Temperature	–40°C to +85°C
Relative Humidity	Up to 95%, non-condensing
Weight	Approximately 1.5 kg
Space Requirements	Two rack positions (positions 1 and 2 reserved)

Main Features and Advantages

Six independent monitoring channels: The 3300/35-13-01-01-00-02 provides six fully independent temperature input channels within a single rack module, maximizing monitoring density without requiring multiple dedicated modules. This high channel count enables comprehensive thermal coverage of a single machine—bearing temperatures, coolant temperatures, and winding temperatures—while conserving valuable rack space.

Flexible RTD compatibility: The 3300/35-13-01-01-00-02 is configured for 3-wire 100 Ω platinum RTDs with an alpha of 0.00392, a widely used industrial standard. The module provides excitation for RTD sensors and performs resistance-to-temperature conversion with channel isolation to reduce measurement coupling between adjacent inputs. Each channel supports individually configurable scaling within the defined sensor curve limits.

Integrated alarm and relay logic: The 3300/35-13-01-01-00-02 includes epoxy-sealed alarm relays for Alert and Danger conditions, with setpoints digitally adjustable from 0 to 100% of full-scale. The relay module installs behind the monitor front panel and offers OR voting logic for relay drive; AND voting requires external wiring of relay contacts in series. This integrated protection capability enables the 3300/35-13-01-01-00-02 to trigger machinery shutdown sequences independently of external control systems.

Comprehensive status indication: Four LED indicators on the 3300/35-13-01-01-00-02 provide at-a-glance system status. The green OK LED indicates overall channel health across all six transducer channels. Alert and Danger LEDs signal alarm conditions independently, with flashing operation denoting a rack First Out condition. The red Bypass LED indicates active bypass functions. Fault detection circuitry identifies open or short RTD wiring conditions and flags channel faults to prevent invalid temperature interpretation.
