Allen-Bradley 2711-T10C9 PanelView 1000 Color Touchscreen Terminal

Brand Allen-Bradley

Model Allen-Bradley 2711-T10C9

Product Overview

The Allen-Bradley 2711-T10C9 is a PanelView 1000 Standard operator terminal designed to provide reliable human-machine interaction in industrial automation environments. As part of the Allen-Bradley PanelView Standard family, the Allen-Bradley 2711-T10C9 combines a 10-inch color active-matrix TFT display with an analog resistive touchscreen interface, delivering clear visual feedback and intuitive operator control for machinery and process systems. This terminal serves as the primary interface between operators and PLC-based control systems, enabling real-time monitoring of process variables, alarm management, and equipment control functions.

The Allen-Bradley 2711-T10C9 distinguishes itself through its robust communication capabilities and durable construction. The terminal features an embedded RS-232 port supporting DH-485 protocol, facilitating seamless integration with Allen-Bradley PLC and SLC controllers, along with a dedicated RS-232 printer port for generating operational reports and data logs. The Allen-Bradley 2711-T10C9 operates on a wide 100-240V AC power supply range, accommodating diverse industrial power environments without requiring external transformers or adapters.

Designed for panel-mount installation, the Allen-Bradley 2711-T10C9 features a NEMA Type 12/13 and IP65 rated front panel, protecting internal components from dust, moisture, and washdown conditions common in manufacturing and processing facilities. With 310 KB of runtime application memory and 1008 KB of flash storage for application objects, the Allen-Bradley 2711-T10C9 supports complex screen designs created with PanelBuilder32 software. The terminal’s ATA memory card compatibility allows for additional storage and application flexibility, while its battery-backed real-time clock ensures accurate timestamping of critical operational data.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	Allen-Bradley 2711-T10C9
Manufacturer	Allen-Bradley (Rockwell Automation)
Product Type	PanelView 1000 Standard Operator Terminal
Display Size	10 inches (10.4-inch diagonal)
Display Type	Color Active-Matrix TFT LCD
Resolution	640 x 480 Pixels (VGA)
Display Area	211 x 158 mm
Backlight Type	Cold Cathode Fluorescent (CCF) – Field Replaceable
Operator Input	Analog Resistive Touchscreen (384 Touch Cells)
Touch Life	1,000,000 Actuations
Communication Ports	RS-232 (DH-485 Protocol), RS-232 Printer Port
Application Memory	310 KB Runtime; 1008 KB Flash Storage
Input Voltage	100-240 V AC, 50/60 Hz
Power Consumption	55 VA Maximum
Operating Temperature	0°C to +55°C
Enclosure Rating	NEMA Type 12/13, IP65 (Front Panel)
Dimensions (Touch)	282 x 370 x 112 mm
Weight	Approximately 2.7 kg

Main Features and Advantages

The Allen-Bradley 2711-T10C9 combines proven PanelView 1000 reliability with communication versatility and operator-friendly design, making it a dependable choice for industrial control applications.

Proven PanelView 1000 Platform: The Allen-Bradley 2711-T10C9 belongs to the widely deployed PanelView Standard series, a platform trusted across manufacturing and process industries for decades. Its Active Matrix TFT display with cold cathode fluorescent backlight delivers clear color graphics and high-level information visibility, enabling operators to monitor instrument status, depict process areas, and assess plant conditions at a glance. The field-replaceable backlight design extends service life and simplifies maintenance.

Versatile Communication Capability: The Allen-Bradley 2711-T10C9 features an embedded RS-232 port supporting DH-485 protocol, providing direct connectivity to Allen-Bradley PLC and SLC controllers. A dedicated RS-232 printer port enables printing of system data, alarm logs, and operational reports without additional hardware. This dual-port architecture makes the terminal suitable for both real-time control and documentation functions.

Robust Industrial Construction: The Allen-Bradley 2711-T10C9 is engineered for demanding industrial environments. Its front panel carries NEMA Type 12/13 and IP65 ratings, protecting against dust ingress, water spray, and washdown procedures. The analog resistive touchscreen rated for 1 million actuations withstands the repetitive input patterns typical of high-volume production environments.

Application Development and Memory: The Allen-Bradley 2711-T10C9 is programmed using PanelBuilder32 software, a mature development environment familiar to Allen-Bradley system integrators. With 310 KB runtime memory and 1008 KB flash storage, the terminal accommodates complex screen architectures containing bitmaps, text elements, and application objects. ATA memory card support provides additional storage capacity for data logging and application backup.
