Description
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 1336T-GT1-SP34B (Assembly: 1336T-LM1EN, 74103-015-52A, 74101-954-52C) |
| Manufacturer | Allen-Bradley (A-B) / Bently Nevada |
| Product Type | Drive Control Board Assembly |
| Series | 1336 PLUS II |
| Function | Gate Trigger / Logic Interface |
| Compatibility | 1336 PLUS II AC Drives |
| Status | Remanufactured / New Surplus |
Main Features and Advantages
The AB 1336T-GT1-SP34B board assembly is distinguished by its exceptional precision in pulse width modulation (PWM) control. By accurately switching the output transistors, the gate board minimizes harmonic distortion and ensures a clean power output to the motor, which translates to cooler operation and extended motor life. The included 1336T-LM1EN logic module enhances this by providing the processing power necessary for real-time adjustments to speed and torque commands.
Furthermore, the 74103-015-52A and 74101-954-52C boards are integral to the system’s reliability. They facilitate crucial communication between the drive’s control logic and external monitoring systems, ensuring that operators have continuous visibility into drive performance. This configuration supports advanced features such as slip compensation and autotuning, which are essential for maintaining consistent process variables even under fluctuating load conditions. The robust design of the AB 1336T-GT1-SP34B ensures it can withstand the electrical noise and thermal stresses common in heavy industrial applications.
Application Field
The AB 1336T-GT1-SP34B drive board assembly is predominantly utilized in industries requiring precise motor control, such as material handling, food and beverage processing, and automotive manufacturing. In conveyor systems, the 1336T-LM1EN logic ensures smooth acceleration and deceleration, preventing product spillage or mechanical shock. The 74103-015-52A interface board is particularly valuable in applications requiring integration with PlantPAx or other distributed control systems (DCS), allowing for seamless data exchange and centralized monitoring.
These boards are also essential in pump and fan control applications where variable torque is required to meet system demand. By using the AB 1336T-GT1-SP34B to regulate motor speed, facilities can achieve significant energy savings compared to traditional mechanical throttling methods. The high reliability of the 74101-954-52C ensures that critical processes remain operational, minimizing downtime and maintaining productivity in continuous process industries.
