ABB 3BHE037864R0101 UFC911 B101 Control Board

Brand ABB

Model ABB 3BHE037864R0101 UFC911 B101

The ABB 3BHE037864R0101 UFC911 B101 is a main control unit (MCU) engineered by ABB for its ACS1000 medium-voltage drive family. As the central processing hub within the drive architecture, the ABB 3BHE037864R0101 UFC911 B101 executes real-time control algorithms, manages internal communication, and orchestrates the operation of multiple power semiconductor devices across the converter system.

The ABB 3BHE037864R0101 UFC911 B101 serves as the primary interface between the drive and external plant control systems, handling commands from DCS/PLC networks while providing comprehensive operational and diagnostic data in return. It processes feedback from motor current and voltage sensors, calculates optimal switching patterns for the IGCT-based power stages, and ensures safe, efficient operation of the entire multi-megawatt conversion chain. The board mounts directly into dedicated slots within the ACS1000 control cubicle, interfacing with local power supplies, gate driver units, and external diagnostic tools.

As a core component of the ACS1000 platform, the ABB 3BHE037864R0101 UFC911 B101 supports ABB’s Direct Torque Control (DTC) technology, enabling precise motor control across the full speed range. Its modular design and comprehensive diagnostic capabilities make it essential for maintaining drive system availability in demanding industrial environments.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	3BHE037864R0101
Type Designation	UFC911 B101
Manufacturer	ABB
Product Type	Main Control Unit (MCU) / Control Board
Primary Application	ACS1000 Medium Voltage Drive
Core Control Technology	Direct Torque Control (DTC)
Processing Hardware	Dual-core ARM Cortex-R4, 1.0 GHz
Control Supply	24 V DC (18–36 V DC tolerance)
Isolation Voltage	≥ 2500 V AC (control to power side)
Communication Interface	2× RJ45 (Modbus TCP/RTU), Fiber Optic DriveBus
Fiber Optic Channels	Up to 6 (trigger + status feedback)
Pulse Configuration	2/4/6/8 pulse
Onboard I/O	16 DI (24 V DC) / 16 DO (24 V DC, 0.5 A each)
Conformal Coating	Yes (moisture, dust, corrosion protection)
Operating Temperature	-20°C to +60°C
Mounting	Drive control cubicle dedicated slot
Certification	CE, UL

Main Features and Advantages

Deterministic High-Performance Control: The ABB 3BHE037864R0101 UFC911 B101 is architected for deterministic, real-time control of complex multilevel power converters. It executes ABB’s proven Direct Torque Control (DTC) algorithm with high precision, enabling full motor torque control at zero speed, fast dynamic response, and accurate speed regulation without encoder feedback in most applications. This results in superior process control, reduced mechanical stress on driven equipment, and optimal energy efficiency for high-inertia loads such as compressors, fans, and large pumps.

Distributed System Orchestration: A key strength of the ABB 3BHE037864R0101 UFC911 B101 lies in its ability to seamlessly manage a distributed network of power cells. Through its optical DriveBus interface, the module coordinates the operation of numerous inverter and rectifier units, ensuring voltage balance, optimal switching patterns, and load sharing. This distributed intelligence architecture enhances system reliability and scalability, allowing power ratings to be matched to application needs by adding or removing power modules, all under the centralized command of a single ABB 3BHE037864R0101 UFC911 B101.

Comprehensive Diagnostics and Serviceability: The ABB 3BHE037864R0101 UFC911 B101 provides an extensive suite of diagnostic tools. It continuously monitors the health of all major drive components, logging faults, warnings, and operational trends. Engineers can access detailed oscilloscope functions, thermal models, and lifetime estimations for critical components such as capacitors. This data, accessible via engineering PC tools, facilitates predictive maintenance and enables rapid fault localization.

Industrial-Grade Protection: The ABB 3BHE037864R0101 UFC911 B101 features conformal coating for protection against moisture, dust, and corrosion, making it suitable for harsh environments including cement plants, mining operations, and other high-particulate industrial settings. The board maintains stable performance across an operating temperature range of -20°C to +60°C.
