Description
- 22f-d4p2n113_a_three_phase_ac_driver
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 22F-D4P2N113 |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Product Type | Adjustable Frequency AC Drive (VFD) |
| Series | PowerFlex 4M |
| Input Voltage | 380–480 V AC, 3-phase |
| Input Frequency | 50/60 Hz |
| Output Voltage | 0–460 V AC |
| Output Current | 4.2 A |
| Output Power | 1.5 kW (2 HP) |
| Output Frequency Range | 0–400 Hz (programmable) |
| Control Method | V/Hz (Volts per Hertz) with slip compensation |
| Frame Size | Frame A |
| Enclosure Rating | IP20, NEMA/UL Open Type |
| Physical Dimensions | 174 × 72 × 136 mm (L × W × D) |
| Weight | Approx. 1.2 kg (2.65 lbs) |
| Communication | RS-485 (Modbus RTU / DSI) |
| Digital Inputs | 5 × 24 V DC |
| Analog Inputs | 2 (0–10V or 4–20mA) |
| Relay Outputs | 2 × Form C, 3 A contacts |
| EMC Filter | Internal CE-compliant filter (included) |
| Brake Chopper | Not included (no internal brake transistor) |
| Mounting | Panel mount or DIN rail (Frame A) |
| Overload Capacity | 150% for 60 seconds |
| Operating Temperature | -10°C to +50°C (derating above 40°C) |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Cooling Method | Natural convection |
| Certifications | UL, c-UL, CE, RoHS, EAC, UKCA |
| Standards | EN 61800-3, EN 61800-5-1 |
| Lifecycle Status | Active |
| Standard Warranty | 1 year |
Main Features and Advantages
Compact design with maximum installation flexibility: The 22F-D4P2N113 is engineered for space-constrained control panels, with its slim 72 mm width allowing multiple drives to be mounted side-by-side in a “Zero Stacking” arrangement at ambient temperatures up to 40°C. Both DIN rail and panel-mount options are supported, giving machine builders the freedom to optimize panel layout. The feed-through wiring design simplifies installation on both new equipment and retrofit projects, reducing wiring time and minimizing the risk of wiring errors.
Integrated CE-compliant EMC filter: Unlike many drives in this class that require an external EMC filter to meet electromagnetic compatibility standards, the 22F-D4P2N113 includes a factory-installed CE-compliant S-type EMC filter. This built-in filtering significantly reduces conducted and radiated electrical noise, ensuring compliance with EN 61800-3 without consuming additional panel space or requiring separate procurement and wiring of an external filter. For OEMs exporting machinery to the European market, this integrated compliance feature eliminates a major certification hurdle.
Built-in RS-485 communication for seamless connectivity: The 22F-D4P2N113 features an integrated RS-485 port supporting Modbus RTU and DSI protocols, enabling direct connection to Rockwell Automation Logix controllers, third-party PLCs, HMIs, and SCADA systems. This allows remote start/stop commands, speed reference adjustments, and real-time monitoring of drive status, output frequency, current, and fault codes from a central control room. For applications requiring DeviceNet, EtherNet/IP, or PROFIBUS connectivity, optional communication modules can be added, making the 22F-D4P2N113 a scalable choice that grows with system architecture.
User-friendly fixed keypad with LED display: The 22F-D4P2N113 includes a fixed digital keypad with a 4-digit LED display and ten status indicator LEDs, providing at-a-glance drive monitoring and straightforward parameter configuration. The intuitive keypad layout allows technicians to quickly adjust acceleration/deceleration times, set motor nameplate data, configure digital and analog I/O functions, and clear fault codes without specialized software or programming cables. This reduces commissioning time and simplifies troubleshooting, particularly valuable for maintenance teams working across multiple machine types.
Robust I/O complement for standalone control: With five 24V DC digital inputs, two configurable analog inputs (supporting 0–10V or 4–20mA signals), and two Form C relay outputs rated at 3 A, the 22F- offers generous I/O capacity for a drive of its size. This eliminates the need for a separate I/O module in many applications—digital inputs can handle start, stop, forward/reverse, and preset speed commands, while analog inputs accept potentiometer or PLC-derived speed references. The relay outputs can signal “drive running,” “fault present,” or “at speed” status to external control systems.
