Allen-Bradley 2711-T10G1 PanelView 1000 Terminal, 85-264 V AC Input

Brand Allen-Bradley

Model Allen-Bradley 2711-T10G1

Product Overview

The Allen-Bradley 2711-T10G1 is a PanelView Standard 1000 operator terminal, a rugged human-machine interface that Rockwell Automation built for machine-level and process-level visualization on the plant floor. In this catalog number, the T designates touch screen operator input, 10 identifies the 10-inch class display, G specifies a grayscale screen rather than a color panel, and 1 denotes the standard configuration combining Remote I/O communication, an RS-232 printer port and an 85-264 V AC power input. The result is a terminal that consolidates data from one or more programmable controllers and presents it as operator graphics, control points, alarms and messages.

At the heart of the 2711-T10G1 is a 10.4-inch active-matrix thin-film transistor grayscale display with a cold cathode fluorescent backlight, offering 640 × 480 pixel resolution across an active area of 211 × 158 mm and rendering four shades of gray. Operator input is handled by an analog resistive touch screen organised as 384 touch cells in a 24-column by 16-row matrix, with each cell measuring 26 × 30 pixels, which is coarse by modern standards but entirely adequate for the large, clearly defined buttons that characterize PanelView Standard applications.

Applications for the 2711-T10G1 are developed in Rockwell’s PanelBuilder32 software and stored in the terminal’s 1008 KB of application memory, with removable memory cards supported for application transfer and backup. Because the platform has been discontinued by the manufacturer, the 2711-T10G1 today is primarily sourced as new-surplus or professionally refurbished stock to keep existing machines running, with PanelView Plus 6 terminals such as the 2711P-T10C4 series representing the manufacturer’s documented migration path when a modernization project is justified.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	2711-T10G1
Manufacturer	Rockwell Automation (Allen-Bradley)
Product Type	Operator Interface Terminal / HMI with Touch Screen
Series / Platform	PanelView Standard 1000 (2711 series)
Display Size	10.4-inch class active-matrix TFT grayscale (211 × 158 mm active area)
Display Resolution	640 × 480 pixels, four shades of gray
Backlight	Cold cathode fluorescent (CCF), field-replaceable, approximately 100,000 hour service life
Operator Input	Analog resistive touch screen, 384 touch cells (24 columns × 16 rows), 26 × 30 pixels per cell
Input Power	85-264 V AC, 47-63 Hz; 55 VA maximum consumption
Heat Dissipation	39 W (132 BTU/hr)
Communication Ports	Remote I/O (RIO) network port; RS-232 printer port
Application Memory	1008 KB for application screens; removable memory card supported
Memory Card Support	Yes, with optional memory card retainer required for UL508 installations
Status Indication	Green LED for normal communication, red LED for hardware fault
Enclosure Rating	NEMA Type 12/13 or 4X (indoor use); IP65-class front panel when properly mounted
Configuration Software	PanelBuilder32 (2711-ND3 and compatible versions)
Operating Temperature	0 °C to +55 °C (32 °F to 131 °F)
Mounting Depth	97 mm enclosure depth; 129 mm with memory card retainer; 220 mm with memory card installed
Dimensions (H × W × D)	Approximately 282 × 422 × 112 mm (11.11 × 16.64 × 4.40 in)
Weight	Approximately 2.9 kg (6.4 lb)
Certifications	UL, cUL, CE, CSA; suitable for Class I/II/III Division 2 hazardous locations as applicable
Lifecycle Status	Discontinued / obsolete; migrate to PanelView Plus 6 (2711P-T10C4 series)

Main Features and Advantages

Proven display and touch technology built for the plant floor: The 2711-T10G1 uses an active-matrix TFT grayscale panel with a 640 × 480 pixel resolution and four gray levels, which delivers crisp text, clear bar graphs and legible process graphics without the colour-rendering limitations of older monochrome LCDs. The analog resistive touch screen works with a gloved hand, a stylus or a bare finger, and because the 384 discrete touch cells are large and fixed, button targets on the 2711-T10G1 are easy for operators to hit reliably even in high-paced production environments.

Native Allen-Bradley network integration: The defining advantage of the 2711-T10G1 in its installed base is its embedded Remote I/O port, which connects directly into the RIO network that countless SLC 500, PLC-5 and legacy machine architectures still depend on. This means the terminal reads and writes controller data without protocol gateways, converters or additional communication modules, and an RS-232 printer port allows alarm and report hard copy to be generated locally. For maintenance teams supporting machines built in the 1990s and 2000s, that native compatibility is the reason the 2711-T10G1 remains in service rather than being replaced outright.

Simple, maintainable application architecture: Applications are created in PanelBuilder32 and stored in 1008 KB of on-board application memory, with removable memory cards enabling fast application transfer, backup and duplication across identical machines. Screens, alarms, messages and data entry objects are configured rather than programmed, and the terminal reports faults through its green and red status LEDs, which makes a first-line diagnosis possible without a laptop. The 2711-T10G1 also supports application download over the network, through a gateway or via pass-through connection, so screens can be updated without physically accessing the terminal.

Industrial enclosure and serviceability: With a NEMA Type 12/13 and 4X indoor front rating, the 2711-T10G1 mounts directly on a panel door and tolerates dust, oil mist and washdown-adjacent environments. The backlight is a field-replaceable component available as a defined spare part, and touch screen overlays, protective films, gaskets, bezels and cases are all replaceable, which means a faded screen or a damaged touch surface does not require scrapping the terminal. Combined with a 0 °C to 55 °C operating range and universal 85-264 V AC input, the 2711-T10G1 continues to deliver dependable service long after newer platforms have entered the market.
