Description
Application Scenarios
In a remote natural gas compression station, maintaining precise engine speed and load control is critical for pipeline throughput and equipment longevity. The site’s legacy control system frequently experienced drift in speed regulation during ambient temperature swings, causing nuisance shutdowns and costly production interruptions. After integrating the CSC3LG120 as the primary engine control module, the station achieved stable speed regulation even as ambient temperatures fluctuated between -30°C and +50°C. The module’s adaptive control algorithms continuously adjusted fuel delivery parameters based on real-time engine feedback, eliminating the manual retuning that previously consumed 4-6 engineering hours per month.
Parameter
| Parameter | Value/Description |
|---|---|
| Product Model | CSC3LG120 |
| Manufacturer | Woodward |
| Product Category | Control Module |
| Supply Voltage | 24 VDC nominal |
| Power Consumption | 5 W typical |
| Operating Temperature | -40°C to +85°C |
| Dimensions | 120 × 100 × 60 mm |
| Weight | 1.2 kg |
| Communication Protocols | CANbus, Modbus |
| Digital I/O | Configurable for sensors, actuators, external systems |
| Control Algorithms | PID, feedforward, adaptive control |
| Certifications | CE, UL |
| Mounting | Panel or control cabinet integration |
