Description
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | MOOG 3AXES |
| Manufacturer | Moog Inc. |
| Product Type | 3-Axis Motion Controller |
| Operating Voltage | 24 VDC |
| Current Consumption | Max. 3A |
| Communication Protocol | EtherCAT, CANopen |
| Max. Input/Output Channels | 16/16 |
| Resolution | 0.1 μm |
| Operating Temperature | −20°C to +60°C |
| Enclosure Protection | IP65 |
| Dimensions (W × H × D) | 120mm × 100mm × 30mm |
| Weight | 0.4 kg |
Main Features and Advantages
The MOOG 3AXES delivers a combination of precision control, robust construction, and communication flexibility that addresses the demands of modern multi-axis industrial automation applications.
Advanced three-axis trajectory control: The MOOG 3AXES employs sophisticated control algorithms to optimize trajectory planning across three independent axes, ensuring smooth, coordinated movements that minimize mechanical stress and enhance positioning accuracy. This capability proves essential in applications requiring synchronized motion between multiple axes, such as pick-and-place systems, CNC positioning stages, and automated assembly equipment.
High-resolution precision: With a resolution of 0.1 μm, the MOOG 3AXES achieves positioning accuracy suitable for the most demanding precision tasks. The controller’s high-resolution stepper motor drivers deliver fine control over movement parameters, enabling applications that require exceptional repeatability and minimal positioning error.
Flexible communication architecture: The MOOG 3AXES supports both EtherCAT and CANopen communication protocols, facilitating seamless integration with a wide range of industrial automation components including servo drives, sensors, and host controllers. This dual-protocol capability ensures compatibility with diverse system architectures and simplifies connectivity with existing equipment.
Robust environmental protection: The IP65-rated enclosure of the MOOG 3AXES provides effective protection against dust ingress and water spray, allowing reliable operation in industrial settings where environmental contaminants present challenges. The controller operates across a temperature range of −20°C to +60°C, accommodating installation in varied industrial environments.
Comprehensive I/O capability: With 16 input and 16 output channels, the MOOG 3AXES provides extensive connectivity for auxiliary sensors, actuators, and interlocks, reducing the need for additional I/O modules and simplifying system architecture. This integrated I/O capacity supports complex control scenarios involving multiple feedback signals and output devices.
