ProSoft 3250-L532M Modbus Slave RTU with SLC 5/03 Instruction Set

Brand ABB

Model ProSoft 3250-L532M

Product Overview

The ProSoft 3150-MCM and ProSoft 3250-L532M are specialized communication interface solutions engineered by ProSoft Technology for seamless integration of Modbus protocol devices into Allen-Bradley PLC and SLC control platforms. These two products represent distinct yet complementary approaches to solving the same fundamental challenge: enabling legacy Rockwell Automation controllers to communicate with third-party Modbus devices without requiring costly controller replacement or complex external gateway hardware.

The ProSoft 3150-MCM is a single-slot, rack-resident Modbus Master/Slave communication module designed for the Allen-Bradley 1746 (SLC 500) and 1771 (PLC-5) I/O platforms. It functions as a tightly integrated Modbus interface that installs directly into the controller chassis, communicating with the host processor via block transfer instructions . This architecture provides deterministic data exchange between the Modbus network and the SLC/PLC data tables, supporting up to 4000 registers of data transfer with both binary and floating-point data types .

The ProSoft 3250-L532M takes a fundamentally different approach. Rather than functioning as a communication coprocessor within an existing controller, the 3250-L532M is a complete Remote Terminal Unit (RTU) built upon the Allen-Bradley SLC 5/03 processor architecture . It combines the processing power and I/O capability of an SLC 5/03 with native Modbus Slave communication on Channel 0, making it an ideal solution for edge-of-network applications where local control and SCADA integration are both required . The 3250-L532M executes standard SLC 5/03 ladder logic locally while simultaneously responding to Modbus polls from a central SCADA or DCS system.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	ProSoft 3150-MCM / ProSoft 3250-L532M
Manufacturer	ProSoft Technology
Product Type	3150-MCM: Modbus Master/Slave Communication Module
	3250-L532M: Remote Terminal Unit (SLC 5/03 Based)
Platform Compatibility	3150-MCM: 1746 (SLC 500), 1771 (PLC-5)
	3250-L532M: SLC 500 Chassis
Communication Ports (3150-MCM)	2 x RS-232/422/485 (DB-9 Male)
Communication Ports (3250-L532M)	1 x RS-232C (DB-9, Modbus Slave)
	1 x DH-485 (RJ45)
	2 x Application Ports (RJ45, RS-232/422/485)
Modbus Modes	RTU and ASCII
Modbus Function Codes	1, 2, 3, 4, 5, 6, 8, 15, 16
Register Capacity (3150-MCM)	4000 registers
I/O Capacity (3250-L532M)	1024 inputs, 1024 outputs
Memory (3250-L532M)	16K
Backplane Current (3150-MCM)	0.15 A @ 5V, 0.04 A @ 24V
Backplane Current (3250-L532M)	500 mA @ 5V, 175 mA @ 24V
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5% to 95% (non-condensing)
Slot Width	Single slot

Main Features and Advantages

The ProSoft 3150-MCM and ProSoft 3250-L532M offer distinct advantages depending on the application architecture, yet both share ProSoft Technology’s commitment to reliable Modbus integration for Rockwell Automation platforms.

Modbus Master and Slave Flexibility (3150-MCM): The 3150-MCM features two independently configurable serial ports, each capable of operating as either a Modbus Master or Slave . This dual-mode capability enables the module to simultaneously poll downstream Modbus devices while responding to polls from an upstream SCADA system, effectively bridging two Modbus networks without external hardware. The module supports both RTU and ASCII transmission modes with CRC-16 and LRC error checking respectively .

Tight SLC/PLC Backplane Integration: The 3150-MCM installs directly into the controller chassis and communicates via the backplane using block transfer (BTW/BTR) instructions . Configuration is accomplished through ladder logic programming, with parameters such as slave address, baud rate, parity, and timeout values all defined in the processor’s data files . The module supports custom memory mapping, allowing users to define specific data table addresses for Modbus register exchange .

Complete RTU Solution (3250-L532M): The 3250-L532M eliminates the need for a separate controller and communication module by integrating SLC 5/03 processing with native Modbus Slave capability . It executes standard SLC 5/03 ladder logic for local control and data acquisition while responding to Modbus polls through its dedicated RS-232C Modbus Slave port . This architecture reduces hardware footprint, simplifies wiring, and provides deterministic local processing for edge applications.

Industrial Hardening: Both products are engineered for harsh industrial environments. The 3150-MCM supports extended temperature ranges and provides 500V optical isolation on communication ports . The 3250-L532M is specifically designed for deployment in oil and gas pipelines, electrical substations, and mining operations where reliability and fault isolation are critical .
