Description
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 22A-D4P0N104 |
| Manufacturer | Allen Bradley (Rockwell Automation) |
| Product Type | Adjustable Frequency AC Drive |
| Series/Product Line | PowerFlex 4 |
| Input Voltage Range | 380-480V AC, 3-Phase |
| Output Voltage Range | 0-460V AC, 3-Phase |
| Output Power | 1.5 kW (2 HP) |
| Output Current | 4.0 Amps |
| Input Current | 5.7 Amps |
| Input kVA | 4 kVA |
| Output Frequency | 0-240 Hz (Programmable) |
| Control Method | Volts/Hertz (V/Hz) with Slip Compensation |
| Enclosure Rating | IP20 (Open Type) |
| Frame Size | Size A |
| Communication | RS-485, Modbus Protocol |
| Brake IGBT | Standard Internal Brake IGBT |
| Interface | Fixed Keypad with 4-Digit Display |
| Filter Option | No Integrated Filter |
| Operating Temperature | -10°C to 50°C (IP20 Open Type) |
| Storage Temperature | -40°C to 85°C |
| Dimensions (H × W × D) | 152 mm × 80 mm × 136 mm |
| Weight | 1.36 kg (3.0 lbs) |
Main Features and Advantages
The 22A-D4P0N104 delivers a practical combination of essential drive functionality, compact design, and ease of use that addresses the core needs of industrial motor control applications.
Compact and Panel-Efficient: The 22A-D4P0N104 occupies minimal panel space thanks to its frame size A dimensions of 152 mm by 80 mm. The drive supports DIN rail mounting for quick installation in standard enclosures, and its zero-stacking capability allows side-by-side mounting without air gaps between adjacent drives, further optimizing cabinet density. This space efficiency is particularly valuable in OEM machinery where panel real estate is at a premium.
Simplified Setup and Operation: The 22A-D4P0N104 ships ready for immediate keypad operation, with control keys and a potentiometer active out of the box. The Basic Program Group organizes the ten most commonly adjusted application parameters for rapid configuration without navigating complex menu structures. The integrated four-digit display and LED indicators provide clear feedback for startup, fault diagnosis, and operational status monitoring, reducing commissioning time and simplifying troubleshooting.
Built-in Protective Features: The 22A-D4P0N104 incorporates comprehensive motor and drive protection functions as standard. Electronic motor overload protection follows an I²t curve providing Class 10 protection (150% for 60 seconds, 200% for 3 seconds), guarding motors against sustained overload conditions. Ground fault protection during startup and running detects insulation failures before they escalate. A removable MOV-to-ground jumper allows compatibility with ungrounded or resistance-grounded distribution systems when properly configured.
Flexible Control and Integration: The 22A-D4P0N104 accepts both 0-10V and 4-20 mA analog speed references, along with configurable digital inputs for start, stop, reverse, and programmable functions. The form C relay output can be configured to indicate fault status or other operational conditions. RS-485 communication supporting Modbus protocol enables integration with PLCs and higher-level control systems for networked motor control architectures.
