Honeywell 51401469-100 Power Supply Module — TPS / TDC 3000 Rack DC System Power for C300 & HPM

Brand Honeywell

Model Honeywell 51401469-100

Product Overview

The Honeywell 51401469-100 is a system power supply module designed for use in Honeywell’s TPS (Total Plant Solution) / TDC 3000 Distributed Control System architecture, where it provides conditioned low-voltage DC power to the controller chassis backplane and the modules seated within it. In a Honeywell DCS cabinet, this unit sits in a dedicated power slot — or mounts to the side of the chassis in certain configurations — and converts the external AC or DC input into the stable logic-level voltages required by controllers, I/O cards, and communication modules. In this sense, the Honeywell 51401469-100 is the foundation of the entire rack: if its output drifts, sags, or fails, every dependent card loses the clean power it needs to execute control reliably.

The Honeywell 51401469-100 belongs to the 51401469 family, which includes related output grades (-120, -140, -150) and is documented in the strongest sources as the TPS Series power module. Its core function is power conversion and distribution: it accepts a wide-range external input (110/220 V AC or 24 V DC depending on system configuration) and regulates it down to the backplane rails — typically +5 V with ±12 V support — that controller and I/O modules draw from. Integrated diagnostics continuously monitor output voltage, current, and internal temperature, while overvoltage, undervoltage, overcurrent, and thermal-protection circuits guard both the supply itself and the expensive electronics downstream.

From a system-value perspective, the Honeywell 51401469-100 is most significant in its role as a redundant, hot-swappable element. TPS/Experion racks commonly deploy two such modules in a primary/standby arrangement; if one fails or loses its input, the other assumes the full load without interrupting control execution. This makes the module a cornerstone of high-availability DCS design. For asset owners maintaining mature TDC 3000 / TPS installations, a verified Honeywell 51401469-100 in the spare-parts inventory is often the difference between a scheduled, minutes-long replacement and an unplanned, full-rack outage — preserving the substantial embedded investment in control strategy, field wiring, and I/O infrastructure.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	Honeywell 51401469-100
Manufacturer	Honeywell
Product Type	System Power Supply Module
Series / Platform	Honeywell TPS Series / TDC 3000 / Experion PKS (C300 / HPM chassis)
Primary Function	Backplane DC power conversion & distribution
Input Voltage	110/220 V AC or 24 V DC (configuration-dependent; auto-ranging on AC)
Output Voltage(s)	+5 V DC primary, ±12 V DC (backplane rails; confirm per revision)
Output Current	Up to 2 A nominal (load-dependent; verify against label)
Power Rating	≈ 50 W class (configuration-specific)
Efficiency	≥ 90 % (typical, regulated switching design)
Line / Load Regulation	± 0.5 % (typical)
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit, thermal shutdown
Diagnostics	Self-diagnostic monitoring of output V, I, and temperature; LED status indicators
Redundancy	Supports 1:1 primary/standby (N+1) deployment
Mounting	Dedicated power slot in controller / I/O chassis, or chassis side-mount
Wiring	Pluggable terminal block (Power In, GND); backplane edge connection
Typical Operating Voltage (load side)	+5.0 to +5.2 V DC
Current Draw (max, representative)	3.5 A (dependent on installed module population)
Operating Temperature	0 °C to +60 °C (32 °F to 140 °F)
Storage Temperature	−40 °C to +85 °C (−40 °F to 185 °F)
Humidity	5 % to 95 % RH, non-condensing
Weight (approx.)	0.5 kg (≈ 1.1 lb; varies by revision)
Dimensions (approx.)	Rack-module form factor (refer to chassis mechanical drawing)
Country of Origin	United States

Main Features and Advantages

Clean, regulated backplane power. The primary strength of the Honeywell 51401469-100 is its ability to deliver tightly regulated DC rails to a chassis full of sensitive control electronics. Tight line and load regulation (±0.5 % typical) keeps the analog-to-digital reference voltages of I/O modules stable, preventing the kind of subtle measurement drift that can be mistaken for a field-instrument fault. For process loops where a few millivolts translate into meaningful control error, this cleanliness is fundamental.

Built-in diagnostics and fault signaling. The module continuously monitors its own output voltage, output current, and internal temperature, and reports status through panel indicators (typically Power, Run, and Fault). When an overvoltage, undervoltage, overcurrent, or thermal limit is reached, the supply reacts quickly — either correcting the condition or safely shutting down the output — to protect the controller and I/O cards downstream. This self-awareness turns a traditionally invisible utility into a diagnosable element of the control system.

Redundancy-ready for high availability. A key advantage of the Honeywell 51401469-100 is its compatibility with the TPS/Experion 1:1 primary/standby power architecture. Two modules share the load under normal conditions; if one fails or loses input power, the surviving unit seamlessly carries the entire chassis without disrupting control execution. In continuous-process industries where an unplanned shutdown carries severe financial or safety consequences, this seamless takeover is the central value proposition.

Wide-input flexibility for global deployment. The module supports common industrial input configurations — 110/220 V AC auto-ranging or 24 V DC — allowing it to integrate with a plant’s existing power distribution without requiring a separate transformer or converter. This flexibility simplifies deployment across regions and makes the Honeywell 51401469-100 a practical standard spare for multinational operations running the same DCS platform in multiple locations.

Comprehensive protection for downstream assets. Integrated overvoltage, overcurrent, short-circuit, and thermal protection does more than safeguard the supply itself: it also shields the controller processor, I/O modules, and communication cards that draw from the same backplane. A single protected supply can therefore prevent a cascade failure that would otherwise take out an entire rack.

Drop-in form factor and lifecycle continuity. Designed to seat directly into the designated chassis power slot or mount to the chassis side, the Honeywell 51401469-100 installs without mechanical modification, separate cabling harnesses, or software configuration. For plants committed to a legacy-asset strategy, this makes the module a low-risk, rapid-replacement spare that defers costly full-rack or full-DCS migration while restoring original reliability.
