Measurex 05293500 X-ray Controller Assembly for Industrial Non-Destructive Testing

Brand ABB

Model Measurex 05293500

Product Overview

The Measurex 05293500 is a high-precision X-ray controller assembly engineered for demanding industrial inspection and non-destructive testing applications. As a critical component within Measurex quality control systems, the Measurex 05293500 integrates advanced radiation detection technology with precision signal processing to deliver accurate material analysis and imaging results. This controller assembly serves as the central interface between X-ray generation equipment and imaging software, ensuring consistent dose control and exceptional image clarity across a wide range of inspection tasks.

The Measurex 05293500 features an ultra-sensitive amplifier design that achieves 0.1% full-scale resolution, enabling detection of fine material variations and defects that less sophisticated systems might miss. With a maximum exposure voltage of 200kV and image processing speeds reaching 10 frames per second, this controller assembly supports efficient throughput without compromising inspection quality. Its compact dimensions allow straightforward integration into existing X-ray inspection lines, while the temperature-controlled design maintains stable operation across industrial environments ranging from -10°C to +50°C.

Positioned as a versatile solution for both medical imaging and industrial non-destructive testing applications, the Measurex 05293500 delivers the precision and reliability that professionals in aerospace, automotive, and metal fabrication sectors depend on for critical quality assurance operations.

Request Price

Description

Technical Specifications

Parameter Name	Parameter Value
Product Model	Measurex 05293500
Manufacturer	Measurex
Product Type	X-ray Controller Assembly
Application Range	Industrial Inspection, Non-destructive Testing, Medical Imaging
Maximum Exposure Voltage	200kV
Amplifier Resolution	0.1% Full Scale
Image Processing Speed	10 Frames per Second
Operating Temperature	-10°C to +50°C
Humidity Range (Non-operating)	5% to 95% RH, non-condensing
Power Consumption	120W
Resolution	0.01 mm
Dose Control Accuracy	±1%

Main Features and Advantages

The Measurex 05293500 distinguishes itself through an integrated design philosophy that prioritizes both imaging precision and operational reliability. Its ultra-sensitive amplifier delivers exceptional signal-to-noise performance, capturing fine details in material structure and thickness variations that are critical for detecting internal defects, inclusions, and dimensional inconsistencies. This level of sensitivity makes the Measurex 05293500 particularly valuable in applications where inspection accuracy directly impacts product safety and performance.

Precision dose control: The controller maintains radiation output within ±1% accuracy, a specification that ensures both consistent imaging results and operator safety through minimized unnecessary exposure. This tight control also supports compliance with industry radiation safety standards, simplifying regulatory documentation for facilities deploying the Measurex 05293500 in production environments.

High-frequency operation: The assembly operates at 60 Hz with a power consumption of 120W, balancing rapid image acquisition with energy efficiency. The ability to process images at 10 frames per second enables real-time inspection workflows, making the Measurex 05293500 suitable for integration into automated production lines where inspection speed is a bottleneck concern.

Durability and integration: Engineered with robust materials and a temperature-controlled architecture, the Measurex 05293500 withstands the vibration, dust, and temperature fluctuations common in manufacturing settings. Its compact form factor and intuitive software interface simplify installation and configuration, allowing technicians to quickly calibrate the system for specific application requirements.
